2. Click Input EDID Section and set the EDID according to the information in the following
table:
Menu Item
EDID Mode
All EDID
In 1~4 EDID
User 1~4
Update
• Copy the desired EDID file
• Select Yes for a selected User.
• Insert the USB memory stick into the
Input EDID is set.
Configuring HDCP Mode
MV-4X enables configuring HDCP on the inputs and outputs.
To configure the HDCP mode:
1. On the front panel press MENU. The menu appears.
2. Click HDCP Mode and define the video parameters according to the information in the
following table:
Menu Item
IN 1~4
OUT A/OUT B
HDCP is configured.
MV-4X – Operating and Controlling MV-4X
Action
Select how to assign the EDID to the device
inputs:
Select All for a single EDID to be assigned to
all the inputs.
Select Appoint for a different EDID to be
assigned to each input.
When in All EDID mode, assign the selected
EDID to all the inputs.
When in Appoint EDID mode, assign a
selected EDID individually for each input (IN
EDID from 1 to 4).
Update the USER EDID:
(EDID_USER_*.BIN) to the root directory
of a USB memory stick
PROG USB port on the rear panel.
The EDID stored in the memory stick uploads
automatically.
Description
Select the HDCP behavior for each input.
Select Off to disable HDCP support on the
selected input.
Set the HDMI output to follow Input or Output.
Kramer Electronics Ltd.
Options
All (default), Appoint
1080P (default), 4K2K3G,
4K2K420, 4K2K6G, Sink Output A,
Sink Output B, User 1, User 2,
User 3, User 4
1080P (default), 4K2K3G,
4K2K420, 4K2K6G, Sink Output A,
Sink Output B, User 1, User 2,
User 3, User 4
For each User: No (default), Yes
Options
Off, On (default)
Follow Output (default), Follow
Input
