Connecting Ethernet Port Directly to a PC
You can connect the Ethernet port of
crossover cable with RJ-45 connectors.
This type of connection is recommended for identifying
with the factory configured default IP address.
After connecting
1. Click Start > Control Panel > Network and Sharing Center.
2. Click Change Adapter Settings.
3. Highlight the network adapter you want to use to connect to the device and click Change
settings of this connection.
The Local Area Connection Properties window for the selected network adapter appears
as shown in
4. Highlight either Internet Protocol Version 6 (TCP/IPv6) or Internet Protocol Version 4
(TCP/IPv4) depending on the requirements of your IT system.
5. Click Properties.
The Internet Protocol Properties window relevant to your IT system appears as shown in
Figure 7 or
MV-4X – Operating and Controlling MV-4X
MV-4X
MV-4X to the Ethernet port, configure your PC as follows:
Figure 6.
Figure 6: Local Area Connection Properties Window
Figure 8.
directly to the Ethernet port on your PC using a
MV-4X
