Operating and Controlling MV-4X
Using Front Panel Buttons
MV-4X
front panel buttons enable the following actions:
•
Selecting an HDMI INPUT
•
Selecting an output (A or B)
•
Directing an input to a selected window using the WINDOW button
buttons (from 1 to 4)
•
Selecting operation modes (MATRIX
•
Controlling and operating
•
Resetting the resolution (to XGA/1080p)
•
Locking the front panel
Controlling and Operating Via the OSD Menu
MV-4X
enables controlling and defining the device parameters via the OSD, using the front
panel MENU buttons.
To enter and use the OSD menu buttons:
1. Press MENU.
2. Press:
▪
ENTER to accept changes and to change the menu settings.
▪
Arrow buttons to move through the OSD menu, which is displayed on the video
output.
▪
EXIT to exit the menu.
The default OSD timeout is set to 10 seconds.
Use the OSD menu to perform the following operations:
•
Setting the Video Mode
•
Selecting the Window Layout Mode
•
Configuring Chroma Key Mode
•
Setting up the Picture Parameters
•
Defining the Audio Output
•
Setting the Input
•
Configuring HDCP Mode
MV-4X – Operating and Controlling MV-4X
1
.
2
.
1
.
4
MV-4X
via the OSD menu buttons (
10
.
on page 11.
on page 12.
on page 14.
on page 14.
Settings on page 15.
EDID on page 15.
on page 16.
, QUAD
5
or PIP
6
9
.
Kramer Electronics Ltd.
3
and the INPUT
modes).
7
and
8
).
10
