RT765E-2 OPERATOR MANUAL
Lube Point
Item
Description

Hoist

92 Main Hoist
93a Auxiliary Hoist
NOTE: Line up the Fill/Drain Plug with the upper cutout hole (A). Let hoist sit idle for 20 minutes for an accurate reading.
Ensure hoist is level and oil is within 21°C ±11°C (70°F ±20°F). If oil level is not visible in sight glass, the hoist may
be underfilled. Oil escaping from vent plug (B) is an indication the hoist may be overfilled. If hoist is over filled,
move the Fill/Drain Plug to the lower cutout hole (C) and drain until oil level falls within the sight glass.
Cable Follower
93b
(Arms)
NOTE: Lubricate more frequently than interval indicated if environmental and/or operating conditions necessitate.
Grove
Approved
Figure No.
Lubricant
AGMA
Extreme
Figure 5-10 Pressure Gear
Lubricant
6829100213
AGMA
Extreme
Figure 5-10 Pressure Gear
Lubricant
6829100213
EP-MPG
Extreme
Pressure
Figure 5-10
Multipurpose
Grease
6829003477
Published 9-04-2014, Control # 364-10
Lube
Lube Interval
Capacity
• Check and fill every
50 hours or weekly
15.5 qt
• Drain and fill every
(14.7 l)
1000 hours or 12
months
• Check and fill every
50 hours or weekly
15.5 qt
• Drain and fill every
(14.7 l)
1000 hours or 12
months
Thoroughly
250 hours or 3 months
coat
LUBRICATION
Application
Oil must be visible in
the sight glass (see
note)
Oil must be visible in
the sight glass (see
note)
Spray on
5
5-25
