3. If extended, fully retract all the boom sections and lower
the boom to minimum elevation to permit ease of
installation of pins and access to the boom nose.
NOTE: The auxiliary boom nose (rooster sheave) does not
have to be removed. However, if reeved, the hoist
cable must be removed from the sheave.
4. Attach the swingaway to the boom nose using steps 5
thru 21 of Erecting The Bi-Fold Boom Extension
Assembly.
5. Extend the boom as necessary to permit sufficient
clearance for installation of the 20 ft (6.1 m) Extension
Insert; then lower it until the tip of the bi-fold extension
assembly is laying on the ground. Block up under the bi-
fold extension, approximately 8 to 10 ft (2.4 to 3.0 m)
ahead of the boom nose.
6. Remove the four retainer clips and attachment pins that
secure the bi-fold extension to the boom nose.
7. Retract the boom leaving the bi-fold extension on the
blocking.
8. Using the main or auxiliary hoist cable, lift the Insert by
the lifting lugs and position it at the base end of the bi-
fold extension.
9. Mate the Insert to the bi-fold extension and install the
four attaching pins and retainer clips removed in step 6.
10. With the hoist cable still attached to the Insert, lift the
assembled unit and move the blocking, erected in step
5, to approximately 8 to 10 ft (2.4 to 3.0 m) ahead of the
boom nose attach end of the Insert.
NOTE: Repeat steps 6 through steps 16 in a similar
manner to install the second Insert if applicable.
11. Lower the bi-fold and insert assembly onto the blocks
and detach the hoist cable.
12. Retract the boom and lower to minimum elevation.
13. Rig the hoist cable for single part line with nothing but
the wedge socket on the end of the cable.
14. Extend the boom and mate the attachment lugs on the
Insert with the anchor fittings on the boom nose. It may
be necessary to raise or lower the boom slightly to mate
the attach lugs.
NOTE: If the Insert attach lug holes are not in lateral
alignment with the holes in the boom nose anchor
fittings to install the pins, adjust the upper and
lower cross strut adjustment screws on the Insert to
align the holes.
15. Remove the retainer clips from the four attachment pins
stowed on the Insert and install them in the attachment
Grove
and anchor fittings on both sides of the boom nose.
Install the retainer clips.
Do not attempt to swing the boom extension around to the
right side of the insert. This could result in damage to the
insert.
16. Slowly elevate the boom and remove the blocking from
under the Insert and bi-fold extension.
17. Refer to steps 22 thru 26 of Erecting The Boom
Extension to erect the fly section, to set the offset, and
rig the hoist cable.

Stowing

NOTE:
1. If the fly section is erected, refer to steps 1 thru 5 of
Stowing The Bi-Fold Boom Extension.
2. Extend the boom approximately 4 to 5 ft (1.22 to 1.52
m). Lower the boom until the sheave is on the ground.
3. Block up under the insert approximately 8 to 10 ft (2.4 to
3.0 m) forward of the boom nose.
4. Remove the retainer clips from the four pins in the
attachment and anchor fittings and remove the
attachment pins. Stow the pins in the holders on the
insert.
5. Retract the boom disengaging the anchor fittings on the
boom nose from the attaching lugs on the insert.
6. Attach a hook to the hoist cable.
7. Attach the hoist cable hook to the lifting lugs on the
insert. Lift the assembly and reposition the blocking
approximately 2.4 to 3 m (8 to 10 ft) forward of the insert
to swingaway attachment points.
8. While supporting the insert with the hoist cable, remove
the retainer clips from the four pins attaching the insert to
the swingaway. Remove the four pins.
9. Remove the insert and position it to one side of the
crane.
10. Position the boom and extend it to engage the boom
nose with the swingaway. Install the four attachment
pins and retainer clips removed in step 8.
11. Stow the swingaway on the side of the main boom using
steps 6 thru 26 of Stowing the Swing-Away Boom
Extension, page 4-17.
Published 9-04-2014, Control # 364-10
SET-UP AND INSTALLATION
CAUTION
Possible Equipment Damage!
If equipped, the folding fly section must be stowed
on the side of the base section.
4
4-21
