RT765E-2 OPERATOR MANUAL
Item Description
Boom Extension Base
1
Section
2 Boom Extension Fly Section
3 Shock Wear Pad and Shim
4 Ramp Wear Pad and Shim
Item
1 Boom Extension Base Section
2 Boom Extension Fly Section
3 Fly Attachment Pin and Hitch Pin
4 Adjusting Bolts
5 Pin Stowage Lug
6 Upper Support
7 Lower Mount Ramp
8 Wear Pad
Grove
Description
Published 9-04-2014, Control # 364-10
SET-UP AND INSTALLATION
3
DETAIL C
1
DETAIL D
8
1
2
4
2
4
3
4
5
7
FIGURE 4-10 continued
4-13
6
4
