The current trim setting is indicated on the screen by a vertical bar. In the example on
the right the lock point of the first brake servo has been offset in the direction of
„stronger braking effect" by 3 trim increments.
T
STEP
STEP
'
TIP !
If you have a second brake servo (vehicle type „5 CH"), the increment size you select
applies to both trim rockers (B and D).
5.3.

ABS = Advanced Braking System (PROFI CAR 707 only)

In the model car racing field ABS corresponds to an intermittent brake: instead of
being applied constantly, the brake is applied then released again continually at
short intervals. This method of braking keeps the vehicle on line better, making it
easier to steer under heavy braking.
In the PROFI CAR the ABS function is activated automatically when the steering
deflection exceeds a variable threshold (TH = threshold point).
'
TIP !
If you set the threshold point to 0%, ABS is effective all the time.
This allows you to try out its effect on a straight stretch of track.
A A
ABS
ABS
Search for menu
point
Select parameter
LP = L ock P oint
Set size of
trim increment
Search for menu
point
Select parameter
Set value
30
STEP
LP
78
%
1 – 10%
ABS
AB
3
%
TH
threshold point 0 – 50%
EF
Effect
Effect
0
OFF
1
soft
...
4
hard
0 – 4
