Proceed to „T-CURV" using the
§
Search for the „IT+" value using the handle button
§
Set the value you want using the digi-adjustor.
In the example shown on the right the set value is 16%.
If you move back to the operating display by pressing any menu button (except
the top line of the screen will alternate between the model name and „START".
'
TIP !
The automatic start function can only be triggered when the operating display is on
the screen
4.3.2.

Initiating the automatic start function using the trigger

This works with all vehicle types. When the trigger is moved from the deadband in
the direction of full throttle for the first time, the following things happen:
§
The timer and lap counter start running, and are shown on the screen (varies
according to the selected timer mode).
§
The set „addition" for initial throttle comes into force (see 4.3.1.).
Once the automatic start is initiated, only the model name appears on the screen.
4.3.3. Initiating the automatic start function with the handle button or trigger
If your model is equipped with separate servos for throttle and brake (vehicle types
„3+1 CH" and „5 CH" ), there are two methods of starting:
§
Lock the brake by pressing the handle button
throttle, and the car will not roll away.
§
When you release the handle button
trigger is not in the deadband.
§
If the trigger is in the deadband (idle) you can release the brake (handle
button). You can then start the car by squeezing the trigger, as described
below.
4.3.4.

Terminating the automatic start phase

When the start phase ends, the program switches off the addition to the initial
throttle setting „IT+", and the throttle response reverse to the „normal" curve (2 or 5
points)..
§
If a 2-point throttle curve is in use, the start phase ends when you move the
trigger to the deadband (idle), or when the throttle trigger exceeds the value
determined by Initial Throttle and IT+.
§
If you have set a 5-point throttle curve, the start phase ends when you move
the trigger into the deadband, or when the throttle trigger exceeds the
fourth point on the throttle curve „4T".
The correlation between these values is illustrated in the diagrams in Section 4.3,
termed the „automatic start function working range".
A
button.
G
the car will start - provided that the
26
G-CURV
G
.
IT+ 16
G
. Now you can blip the
%
A
),
