Summary of Contents for Multiplex PROFI mc 4000

  • Page 98 PROFI mc 4000 PROFI mc 4000 Supplement to Manual (for Version 2.0) What is q Tips ⇔ ⇔ changed We have received many ideas for new features from – discontinued? users, and we have incorporated these in Version 2.0 of the software in so far as they are possible and sen- sible.
  • Page 99 PROFI mc 4000 PROFI mc 4000 Version 2.0 1. Copying flight modes TIP: If you find that you cannot alter the destination when you press the w button, you have selected a base This is how it used to work: type which only includes one flight mode.
  • Page 100 Pressing the x button opens the field for selecting a switch. You can select any type of switch which is Assign mixer input switches. available on your PROFI mc 4000. If you wish to SOFT-SW_ SLOW_ reverse the direction of operation of any switch in this menu, press the y button.
  • Page 101 PROFI mc 4000 PROFI mc 4000 Version 2.0 The graphic display shows an approximation of any FIXED VAL.+ 15%_ change you make to the selected point. The exact numeric value and the number of the point currently The fixed value can be set to any point between 0% selected are shown on the right-hand edge of the and 100%.
  • Page 102 PROFI mc 4000 PROFI mc 4000 Version 2.0 3. Defining logic-coupled switches 3. Logic-coupled switches Assign switches The logical switches fulfil a wish which we have heard from many modellers: LOGICAL SW:LOG1 Ä „I want my airbrakes to be locked unless and until I ;INPUT 1...
  • Page 103 PROFI mc 4000 PROFI mc 4000 Version 2.0 1. Fixed value (brake open) = +100% This is how Standard Trim works: The second method of trimming - Standard Trims - ;SERVO 1:SERVOMIX offsets the entire working range, i.e. the behaviour of ,1:FIXED VAL LOG1*Ä...
  • Page 104 (optional) Memory 1 88% free This is how it used to work: -------------------- The PROFI mc 4000’s model memory could store ;NAME COPYÄ data for 25 to 100 models depending on their com- ,TRIMCHECK CHANGE_ plexity. Many users exhausted even this capacity and were obliged to store settings for rarely used models on their PC.
  • Page 105 PROFI mc 4000 PROFI mc 4000 Version 2.0 Slow for mixer input Open „Servo“ select field and select the servo ;SERVO 5:ELEV.+ Open the „Input“ adjust field and select INPUT 2:ELEVATOR Ä the input to be adjusted ,02.0sec' #01.0sec_ The input line only appears if more...
  • Page 106 PROFI mc 4000 PROFI mc 4000 Version 2.0 This is how it works now: 6.4 Servos as input for analogue Starting from the centre point of a transmitter control switches and control switches a value can now be changed equally for both direc- tions of travel.
  • Page 107 OP.TIME_ characteristic and is operated by transmitter con- trol A. If you set up this example in your PROFI mc 4000 to try it out, you can check its effect very simply by 6.8 Changing base type running the servo monitor in Menu 5.
  • Page 108 If you do not personally The default setting for this base type is that aileron possess the PC program for the PROFI mc 4000, differential is switched on and set to 50% in all flight your local specialist MPX dealer may be able to help modes.
  • Page 109 This is how DIRECT THROTTLE works: With these new options the PROFI mc 4000 can Direct throttle has second-highest priority after AUTO- now: ROTATION.
  • Page 110 PROFI mc 4000 PROFI mc 4000 Version 2.0 You will find the switch for DIRECT THROTTLE un- der the options for the COLLECTIVE PITCH control. CONTR D :COL.PITCHÄ ;DIR.THROT ,S06'* In the base types the switch S06 is assigned here as standard.
  • Page 111 PROFI mc 4000 PROFI mc 4000 Version 2.0 2. Open the adjust fields for SLOW (g or w) This is how to set an idle value of 15%: The times for the motor running up and running 1. Select the IDLE-UP control, then the TRAVEL down can be adjusted separately.
  • Page 112 PROFI mc 4000 PROFI mc 4000 Version 2.0 Now you can open the switch select field by 10. Gyro suppression pressing w, and select the analogue switch V1. The analogue switch must now be reversed with the y button to ensure that gyro effect is dimin-...
  • Page 113 PROFI mc 4000 PROFI mc 4000 Version 2.0 Pre-set mixer values in the UNIVERSAL base type For fixed-wing models: For helicopters: Default Default Mixer Inputs Mixer Inputs input values input values ELEV+ TAILROTOR -100/ 0 / +100% -100/ 0 / +100%...
