Removal and
Replacement of
The Power
Supply Assembly
Power Supply
Retaining Screws (4)
Maintenance 5-6
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
To remove and install the power supply assembly from the
mainframe. Refer to Figure 5-3 and perform the steps below.

Figure 5-3, Removing The Power Supply

1264C User Manual
EADS North America Defense
Test and Services, Inc. © 1998
