Installing Blanking Panels; Figure 2-2, Blanking Panels - Eads Racal Instruments 1264C Manual

Installing
Blanking Panels
Mounting Screws
(Top and Bottom)
Blank Panel
Configuring The 1264C 2-4
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
In order to optimize system performance, install optional blanking
panels (P/N 404836) into unused or C-size empty slots. Secure
with two captive mounting screws. Refer to Figure 2-3.

Figure 2-2, Blanking Panels
