Figure 4-1, Functional Block Diagram For 1264C Mainframe
Understanding The 1264C 4-2
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Fan Mounting Enclosure (456653)
F1 Fan
Rear Panel (456647)
P2 (SLOT 0-5)
P300
J300
Switch
Backplane (405130)
P1 (SLOT 0-5)
J50
E1 TO E14
P50
P301
J301
PS1 P/S
PS1-RS
PS1-PF
P2
J2
J1
MONITOR (405141)
TEMP LED
FAN LED
VOLTAGE MONITOR LED's
