Figure 3-2, 1264C Rear View
Refer to Figures 3-1 and 3-2 and the description below.
1. Set front panel AC power switch S100 to the "O" or off
position.
2. Connect the AC Power cord at J400 to the AC power
source – 115 VAC (if S400 is set for 115VAC) for the
standard 1264C, or 230 VAC (if S400 is set for 230VAC) if
Option 71 is installed.
3. Turn the chassis on by setting the front panel switch S100
to the "I" or ON position.
1264C User Manual
J400
AC MAINS Input
