Getting Started
To properly install an Symbio™ 800 AdaptiView display
upgrade kit, the technician must have good knowledge of
the Symbio 800 control systems. Training in Symbio 800
controls is highly recommended before beginning this
upgrade.
Nameplate
A Symbio™ 800 AdaptiView display upgrade nameplate is
included in the kit to be installed near the original
nameplate on the control panel. Always provide the model
number and serial number information from the
nameplate when making inquiries, ordering parts, or
literature for the Symbio 800 AdaptiView display system.
Symbio 800 AdaptiView Display
Upgrade Kit Contents
Table 1.
Basic bill of material for Symbio™ 800 control upgrade kit
Description
Display arm
Symbio AdaptiView color display
Symbio 800 controller
Harness; Modbus distribution
Four plug Phoenix type terminal connector
DIN Rail end stop
Ethernet cable for Symbio 800 to display connection,
3700 mm in length (See,
Figure 2, p.
Male to Female wire harness extension, 1 meter in
length (See,
Figure 3, p.
8)
Wire harness extension, Female connector to stripped
end, 1 meter in length (Refer to
2-conductor power supply communication cable, 8
inches in length (See,
Figure 4, p.
USB Type B service port cable (See,
USB Type B service port cap
Bushing, 0.88 inch diameter
Power supply (for installation as 1A2 power supply)
Power supply mounting bracket
10-32 x 0.50-inch screw
5/16-18 x 1 inch hex head cap screw
5/16-inch lockwasher
5/16-inch hex nut
Serialized nameplate decal
Nameplate protector
10-32 x 1.00-inch screw
Quad relay output
Bracket; CH531 sub panel
CDUB-SVN001B-EN
Qty.
1
1
1
1
2
2
1
8)
1
1
Figure 3, p.
8)
1
8)
Figure 5, p.
8)
1
1
2
1
1
4
4
4
4
1
1
1
1
1
Figure 1.
Symbio™ 800 AdaptiView display upgrade
nameplate example
SYMBIO 800 UPGRADE CONTROL FOR USE ON
LIQUID CHILLERS
MODEL NO: CDUB3A105AA00100000
SERIAL NO: L22C01079
ORDER NO: LARRYSP4
ORIGINAL SERIAL NO: L22A00000
LITERATURE:
CDUB-SVN01*-EN
CTV-SVU004*-EN
CVRF-SVP001*-EN
CTV-SVD005*-EN
www.trane.com/Patent
(a)
Part Number
X45091462010
X13760359001
X13651678020
453730970001
X19220085030
X13492732001
X19070632020
X19051623010
X19051625020
X19051243010
X19140818010
X19201118010
X19100013000
X13650737060
X19090702010
X25330033410
X25012400000
X22020400000
X28020700000
X39001817010
X39001166030
X25330033450
X13650806050
507104470100
CVHE-SVX005*-EN
BAS-SVU047*-EN
CTV-SVP004*-EN
Mnemonic Part
Number(a)
ARM00848
MOD03183
MOD02979
WIR10397
CON00431
CAB01206
CAB01149
CAB01155
CAB00974
CAB01260
CAP01053
BUS00866
BRD02102
BRK03306
SCR00889
SCR01839
SCR01014
BRD04879
BRK05365
7
