Chapter 1: Introduction

1.3 System Features

The following table is an overview of the main features of the 5019C-M4L server.
System Features
Motherboard
X11SCL-LN4F
Chassis
SC512F-350B1
CPU
Intel Xeon E-2200/2100, 9th/8th Generation Core i3, Pentium, or Celeron (in Socket H4 - LGA 1151) with a
thermal design power (TDP) of up to 95W and six cores
Memory
Up to 128 GB of unbuffered (UDIMM) DDR4 (288-pin) ECC memory with speeds of up to 2666MHz in four
memory slots
Chipset
Intel C242
Expansion Slots
One PCI-Express 3.0 x16
Storage Drives
Internal SATA drives: up to two 3.5" or up to three 2.5"
One M.2 slot for PCI-Express 3.0 x4 (Supports M-Key 2280 / 22110 and Intel Optane Memory)
Power
350 W redundant 80Plus Platinum level modules
Cooling
Two 4-cm counter-rotating fans, CPU heatsink, air shroud to direct air flow
Input/Output
USB: Two USB 2.0 ports, two USB 3.1 Gen 1 ports on the rear I/O panel
One serial header; one VGA port
LAN ports
Four 1GbE BASE-T ports (Intel i210)
One dedicated IPMI port
Form Factor
1U rackmount; (WxHxD) 17.2 x 1.7 x 14.5 in. (437 x 43 x 369 mm)
