3.2 Accessing the System

The chassis features a removable top cover.
Removing the Top Cover
1. Remove the screws securing the cover to the chassis.
2. Slide the cover toward the rear of the chassis.
3. Lift the cover from the chassis.
Check that all ventilation openings on the top cover and the top of the chassis are clear and
unobstructed.
Caution: Except for short periods of time, do not operate the server without the cover in place.
The chassis cover must be in place to allow for proper airflow and to prevent overheating.
Screws
Chapter 3: Maintenance and Component Installation
Figure 3-1. Removing the Chassis Cover
25
Screws
Screw
