Summary of Contents for Supermicro SuperServer 5019D-4C-FN8TP

  • Page 1 SuperServer ® 5019D-4C-FN8TP User's Manual Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 About this Manual This manual is written for professional system integrators and PC technicians. It provides information for the installation and use of the SuperServer 5019D-4C-FN8TP. Installation and maintenance should be performed by experienced technicians only. Please refer to the 5019D-4C-FN8TP server specifications page on our website for updates on supported memory, processors, and operating systems (http://www.supermicro.com).

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Server Chassis Features ....................10 Control Panel ........................10 Front Features ........................11 1.5 Motherboard Layout ......................12 Quick Reference Table ......................13 Chapter 2 Server Installation 2.1 Overview ..........................16 2.2 Preparing for Setup ......................16 Choosing a Setup Location ....................16...
  • Page 5 SuperServer 5019D-4C-FN8TP User's Manual 3.4 Chassis Components ......................26 Hard Drives ........................26 Installing a 3.5" Fixed Hard Drive ..................26 Installing 2.5" Fixed Hard Drives ...................28 Expansion Card .........................29 System Cooling .........................30 System Fan Failure .......................30 Checking the Chassis Airflow ..................31 Power Supply ........................31 Chapter 4 Motherboard Connections 4.1 Power Connections ......................33...
  • Page 6 Preface Appendix A BIOS Codes Appendix BStandardized Warning Statements for AC Systems Appendix C System Specifications Appendix D UEFI BIOS Recovery Appendix E Dual Boot Block...
  • Page 7 SuperServer 5019D-4C-FN8TP User's Manual Contacting Supermicro Headquarters Address: Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V.

  • Page 8: Overview

    *Note: Required for configurations with four 2.5" HDDs. 1.2 Unpacking the System Inspect the box that the SuperServer 5019D-4C-FN8TP was shipped in and note if it was damaged in any way. If any equipment appears damaged, file a damage claim with the carrier who delivered it.

  • Page 9: System Features

    Chapter 1: Introduction 1.3 System Features The following table provides an overview of the main features of the 5019D-4C-FN8TP. Refer to Appendix C for additional specifications. System Features Motherboard X11SDV-4C-TP8F Chassis SC505-203B Intel® Xeon® D-2123IT SoC with a TDP of up to 60W Socket Type Embedded Processor Memory...

  • Page 10: Server Chassis Features

    SuperServer 5019D-4C-FN8TP User's Manual 1.4 Server Chassis Features Control Panel The switches and LEDs located on the control panel are described below. The control panel is located next to the left handle of the chassis. See Chapter 4 for details on the control panel connections.

  • Page 11: Front Features

    Chapter 1: Introduction Information LED Status Description An overheat condition has occurred (possibly caused by cable Continuously on and red congestion). Blinking red (1Hz) Fan failure. Check for an inoperative fan. Blinking red (0.25Hz) Power supply failure. Local UID has been activated. Use this function to locate Solid blue the server in a rack environment.

  • Page 12: Motherboard Layout

    SuperServer 5019D-4C-FN8TP User's Manual 1.5 Motherboard Layout Below is a layout of the X11SDV-4C-TP8F with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4.

  • Page 13: Quick Reference Table

    Chapter 1: Introduction Quick Reference Table Jumper Description Default Setting JBT1 CMOS Clear Open: Normal, Closed: Clear CMOS JI2C1, JI2C2 SMB to PCI-E Slots Enable/Disable Pins 2-3 (Disabled) JNS1 Mini-SAS HDD NVMe/SATA Mode Select Pins 1-2: SATA (Default), Pins 2-3: NVMe JPG1 Onboard VGA Enable Pins 1-2 (Enabled)
  • Page 14 SuperServer 5019D-4C-FN8TP User's Manual Connector Description JSD1 SATA Disk On Module (DOM) Power Connector JSIM1 Nano SIM Slot for M.2 B-Key WAN card support JSMB1 System Management Bus Header JSTBY1 +5V Standby Power Header JTGLED1 LAN7/LAN8 Activity LED Header JTGLED2...
  • Page 15 Chapter 1: Introduction DDR4 1866/2133/2400 DDR4 1866/2133/2400 JLAN2 JLAN1 PCIE 3.0 x8 PCIE 3.0 x4 JPCIE1 SLOT7 PCIE 3.0 x8 I350 AM4 PE2[15:12] PE2[7:0] PCIE 3.0 x16 PE1[15:0] JPCIE2 SLOT6 PCIE 3.0 x16 PCIE 3.0 x4 PE2[11:8] M.2(M-key)CONN JLAN3 10G PHY SATA3.0#5 X557-AT2 Flexible I/O...

  • Page 16: Chapter 2 Server Installation

    SuperServer 5019D-4C-FN8TP User's Manual Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory, etc., refer to Chapter 4 for details on installing those components.

  • Page 17: Server Precautions

    Chapter 2: Server Installation • In single-rack installations, stabilizers should be attached to the rack. In multi-rack instal- lations, the racks should be coupled together. • Always verify that the rack is stable before extending a server or other component from the rack.

  • Page 18: Mechanical Loading

    SuperServer 5019D-4C-FN8TP User's Manual Mechanical Loading Equipment should be mounted into a rack so that a hazardous condition does not arise due to uneven mechanical loading. Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring.

  • Page 19: Installing The System Into A Rack

    Chapter 2: Server Installation 2.3 Installing the System into a Rack This section provides information on installing the SC505 chassis into a rack unit. Due to the variety of rack units on the market, the assembly procedure might differ slightly. Also refer to the installation instructions that came with the rack unit you are using.

  • Page 20: Chapter 3 Component Installation And Maintenance

    SuperServer 5019D-4C-FN8TP User's Manual Chapter 3 Component Installation and Maintenance This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and part numbers given. Remove power from the system and remove the top cover before installing or replacing components.
  • Page 21 Chapter 3: Component Installation and Maintenance Figure 3-1. Removing the Chassis Cover...

  • Page 22: Motherboard Components

    SuperServer 5019D-4C-FN8TP User's Manual 3.3 Motherboard Components Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any possible damage. Memory Support The X11SDV-4C-TP8F motherboard supports up to 256 GB of ECC RDIMM or 512 GB of ECC LRDIMM DDR4 memory with speeds of up to 2133 MHz speed in four memory slots.

  • Page 23: Dimm Module Population Sequence

    Chapter 3: Component Installation and Maintenance DIMM Module Population Sequence When installing memory modules, the DIMM slots should be populated in the following order: DIMMB1, DIMMA1, DIMME1, DIMMD1. • Always use DDR4 DIMM modules of the same type, size, and speed. •...

  • Page 24: Dimm Installation

    SuperServer 5019D-4C-FN8TP User's Manual DIMM Installation JPB1:(debug only) PRESS FIT JPL1: 1-2:ENABLE 2-3:DISABLE 1. Insert the desired number of DIMMs into LAN 3/4 IPMI_LAN LAN 1/2 USB 4/5 (3.0) the memory slots, starting with DIMMB1, LEDM1 LAN 5/6 JPG1 DIMMA1, DIMME1, DIMMD1. For best...

  • Page 25: Motherboard Battery

    Chapter 3: Component Installation and Maintenance Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 26: Chassis Components

    SuperServer 5019D-4C-FN8TP User's Manual 3.4 Chassis Components Hard Drives The chassis supports up to one 3.5" or four 2.5" HDDs when AOC area is not occupied, and one PCI-E expansion card. The following configurations are supported: • One 3.5" HDD and a low-profile PCI-E expansion card.
  • Page 27 Chapter 3: Component Installation and Maintenance Figure 3-3. One 3.5" HDD and One Low-Profile Expansion Card...

  • Page 28: Installing 2.5" Fixed Hard Drives

    SuperServer 5019D-4C-FN8TP User's Manual Installing 2.5" Fixed Hard Drives You can install between one and four 2.5" HDDs in various configurations. If two or fewer 2.5" HDDs are installed, you can also add a full-height, half-length PCI-E expansion card. If you want to install four 2.5" HDDs, two dual 2.5" fixed HDD brackets are required. Refer to the parts list table in Section 1.1.

  • Page 29: Expansion Card

    Chapter 3: Component Installation and Maintenance Expansion Card The chassis supports one PCI-E expansion card installed with one 3.5" or two 2.5" HDDs. Refer to the supported configurations list in the beginning of this section. Only install expansion cards after the HDDs are installed. Installing an Expansion Card Begin by removing power from the system as described in Section 3.1 and removing the cover as described in Section 3.2.

  • Page 30: System Cooling

    SuperServer 5019D-4C-FN8TP User's Manual System Cooling Up to three fans provide cooling for the system. The chassis top cover must be installed properly and form a tight seal so that the cooling air can circulate properly through the chassis. System Fan Failure Fan speed is controlled by system temperature via IPMI.

  • Page 31: Checking The Chassis Airflow

    - 240V input voltage. If the power supply module fails, the system shuts down and you must replace the module. Replacement units can be ordered directly from Supermicro. Replacing the Power Supply Begin by removing power from the system as described in Section 3.1 (even if the server is offline) and removing the cover as described in Section 3.2.
  • Page 32 SuperServer 5019D-4C-FN8TP User's Manual Mounting Through-Holes Power Supply Module Rear Mounting Screws Insert Bottom Mounting Screws from Underside Figure 3-7. Replacing the Power Supply...

  • Page 33: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 34: Headers And Connectors

    SuperServer 5019D-4C-FN8TP User's Manual Secondary Power Connector JPV1 must also be connected to the power supply. This connector is used to power the process and provides alternative power for special enclosure when the 24-pin ATX power is not in use.
  • Page 35 NC = No Connection NVMe I C Header JNVI2C1 is a management header for the Supermicro AOC NVMe PCI-E peripheral cards. Connect a corresponding I C cable to this header. Refer to the table below for pin definitions. C Header...
  • Page 36 SuperServer 5019D-4C-FN8TP User's Manual Standby Power The +5V Standby Power header is located at JSTBY1 on the motherboard. You must have a card with a Standby Power connector and a cable to use this feature. Refer to the table below for pin definitions.
  • Page 37 Chapter 4: Motherboard Connections TPM/Port 80 Header A Trusted Platform Module (TPM)/Port 80 header is located at JTPM1 to provide TPM support and a Port 80 connection. Use this header to enhance system performance and data security. Refer to the table below for pin definitions. Trusted Platform Module Header Pin Definitions Pin#...
  • Page 38 SuperServer 5019D-4C-FN8TP User's Manual LAN Activity LED Headers JTGLED1 is the activity LED header for LAN7 and LAN8, and JTGLED2 is the activity header for LAN5 and LAN6. LAN Activity LED LAN Activity LED Pin Definitions Pin Definitions Pin# Definition...

  • Page 39: Rear I/O Ports

    Chapter 4: Motherboard Connections 4.3 Rear I/O Ports See Figure 4-1 below for the locations and descriptions of the various I/O ports on the rear of the motherboard. JPB1:(debug only) PRESS FIT JPL1: 1-2:ENABLE 2-3:DISABLE IPMI_LAN LAN 3/4 LAN 1/2 USB 4/5 (3.0) LEDM1 LAN 5/6...
  • Page 40 SuperServer 5019D-4C-FN8TP User's Manual VGA Port A VGA video port is located near LAN ports 7/8 on the I/O back panel. LAN Ports There are eight LAN ports located on the I/O back panel of the motherboard. LAN1 - LAN4 are RJ45 1GbE Ethernet ports, LAN5 - LAN6 are 10GbE ports, and LAN7 - LAN8 are 10G SFP+ ports.
  • Page 41 Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, please refer to the IPMI User's Guide posted on our website at https://www.supermicro.com/ support/manuals/. UID Button...

  • Page 42: Front Control Panel

    JF1 contains header pins for various buttons and indicators that are normally located on a control panel at the front of the chassis. These connectors are designed specifically for use with Supermicro chassis. See the figure below for the descriptions of the front control panel buttons and LED indicators.
  • Page 43 Chapter 4: Motherboard Connections Power Button The Power Button connection is located on pins 1 and 2 of JF1. Momentarily contacting both pins will power on/off the system. This button can also be configured to function as a suspend button (with a setting in the BIOS - see Chapter 6). To turn off the power when the system is in suspend mode, press the button for 4 seconds or longer.
  • Page 44 SuperServer 5019D-4C-FN8TP User's Manual NIC1/NIC2 Activity LED The NIC (Network Interface Controller) LED connection for LAN port 1 is located on pins 11 and 12 of JF1, and the LED connection for LAN port 2 is on pins 9 and 10. Attach the NIC LED cables here to display network activity.

  • Page 45: Jumpers

    Chapter 4: Motherboard Connections 4.5 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 46 SuperServer 5019D-4C-FN8TP User's Manual LAN Port Enable/Disable Use jumper JPL1 to enable or disable LAN1 - LAN4. Refer to the table below for jumper settings. LAN Enable/Disable Jumper Settings Jumper Setting Definition Pins 1-2 Enabled (Deafult) Pins 2-3 Disabled Manufacturing Mode Select...
  • Page 47 Chapter 4: Motherboard Connections SMBus to PCI-E Slots Use jumpers JI2C1 and JI2C2 to enable PCI-E SMB (System Management Bus) support to improve system management for the onboard PCI-E slot. SMBus to PCI-E Slots Jumper Settings Jumper Setting Definition Pins 1-2 Enabled Pins 2-3 Disabled (Default)

  • Page 48: Led Indicators

    SuperServer 5019D-4C-FN8TP User's Manual 4.6 LED Indicators LAN LEDs Eight LAN ports (LAN1 - LAN8) are located on the I/O back panel. Each Ethernet LAN port has two LEDs. The green LED indicates activity, while the other Link LED may be green, amber, or off to indicate the speed of the connection.

  • Page 49: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 50 SuperServer 5019D-4C-FN8TP User's Manual 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner.

  • Page 51: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to to a USB flash drive or a DVD.

  • Page 52: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 53: Ipmi

    The X11SDV-4C-TP8F supports the Intelligent Platform Management Interface (IPMI). IPMI is used to provide remote access, monitoring and management. There are several BIOS settings that are related to IPMI. For general documentation and information on IPMI, please visit our website at: http://www.supermicro.com/products/nfo/IPMI.cfm.

  • Page 54: Chapter 6 Uefi Bios

    SuperServer 5019D-4C-FN8TP User's Manual Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the AMIBIOS™ Setup utility for the X11SDV-4C-TP8F motherboard. The is stored in a flash chip and can be easily upgraded using a floppy disk-based program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 55: Main Menu

    Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is the BIOS build date after RTC reset. Supermicro X11SDV-4C-TP8F BIOS Version This feature displays the version of the BIOS ROM used in the system.

  • Page 56: Advanced Settings Menu

    SuperServer 5019D-4C-FN8TP User's Manual 6.3 Advanced Settings Menu Use this menu to configure advanced settings. Warning: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency or an incorrect BIOS timing setting may cause the system to malfunction.
  • Page 57 Chapter 6: UEFI BIOS Bootup NumLock State Use this feature to set the Power-on state for the Numlock key. The options are Off and On. Wait For "F1" If Error This feature forces the system to wait until the F1 key is pressed if an error occurs. The options are Disabled and Enabled.
  • Page 58 SuperServer 5019D-4C-FN8TP User's Manual CPU Configuration  The following CPU information will display: • Processor BSP Revision • Processor Socket • Processor ID • Processor Frequency • Processor Max Ratio • Processor Min Ratio • Microcode Revision • L1 Cache RAM •...
  • Page 59 Chapter 6: UEFI BIOS PPIN Control Select Unlock/Enable to use the Protected Processor Inventory Number (PPIN) in the system. The options are Unlock/Disable and Unlock/Enable. Hardware Prefetcher (Available when supported by the CPU) If set to Enable, the hardware prefetcher will prefetch streams of data and instructions from the main memory to the L2 cache to improve CPU performance.
  • Page 60 SuperServer 5019D-4C-FN8TP User's Manual Power Performance Tuning This feature allows the user to set whether the operating system or the BIOS controls the Energy Performance BIAS (EPB). The options are OS Controls EPB and BIOS Controls EPB. *If the feature above is set to BIOS Controls EPB, the following features will be...
  • Page 61 Chapter 6: UEFI BIOS Hardware PM State Control  Hardware P-States This setting allows the user to select between OS and hardware-controlled P-states. Selecting Native Mode allows the OS to choose a P-state. Selecting Out of Band Mode allows the hardware to autonomously choose a P-state without OS guidance. Selecting Native Mode with No Legacy Support functions as Native Mode with no support for older hardware.
  • Page 62 SuperServer 5019D-4C-FN8TP User's Manual Chipset Configuration  Warning: Setting the wrong values in the sections below may cause the system to malfunction. North Bridge Configuration  UPI Configuration  The following UPI information will display: • Number of CPU •...
  • Page 63 Chapter 6: UEFI BIOS Sub NUMA Clustering (SNC) is a feature that breaks up the Last Level Cache (LLC) into clusters based on address range. Each cluster is connected to a subset of the memory controller. Enabling SNC improves average latency and reduces memory access conges- tion to achieve higher performance.
  • Page 64 SuperServer 5019D-4C-FN8TP User's Manual Memory Topology  This feature displays the information of onboard memory modules as detected by the BIOS. Memory RAS Configuration  Static Virtual Lockstep Mode Select Enable to run the system's memory channels in lockstep mode to minimize memory access latency.
  • Page 65 Chapter 6: UEFI BIOS Patrol Scrub Patrol Scrub is a process that allows the CPU to correct correctable memory errors detected on a memory module and send the correction to the requestor (the original source). When this feature is set to Enable, the IO hub will read and write back one cache line every 16K cycles if there is no delay caused by internal processing.
  • Page 66 SuperServer 5019D-4C-FN8TP User's Manual PCI-E Port Link Status This feature shows the status of the device plugged into this slot. PCI-E Port Link Max This feature shows the status of the device plugged into this slot. PCI-E Port Link Speed This feature shows the status of the device plugged into this slot.
  • Page 67 Chapter 6: UEFI BIOS Prioritize TPH Use this feature to enable Prioritize TPH support. The options are Enable and Disable. Relaxed Ordering Select Enable to enable Relaxed Ordering support, which will allow certain transac- tions to violate the strict-ordering rules of PCI bus for a transaction to be completed prior to other transactions that have already been enqueued.
  • Page 68 SuperServer 5019D-4C-FN8TP User's Manual Intel® VMD Technology  Intel® VMD for Volume Management Device on CPU  VMD Config for PStack0 Intel® VMD for Volume Management Device Select Enable to use the Intel Volume Management Device Technology for this stack.
  • Page 69 Chapter 6: UEFI BIOS Port 60/64 Emulation Select Enabled for I/O port 60h/64h emulation support, which in turn, will provide complete legacy USB keyboard support for the operating systems that do not support legacy USB devices. The options are Disabled and Enabled. Server ME Configuration ...
  • Page 70 SuperServer 5019D-4C-FN8TP User's Manual *If the feature "Configure SATA as" above is set to RAID, the following features will be available for configuration: SATA RSTe Boot Info Select Enable to provide full int13h support for the devices attached to SATA controller. The options are Disable and Enable.
  • Page 71 Chapter 6: UEFI BIOS SATA HDD Unlock This feature allows the user to remove any password-protected SATA disk drives. The options are Disable and Enable. Aggressive Link Power Management When this feature is set to Enable, the SATA AHCI controller manages the power usage of the SATA link.
  • Page 72 SuperServer 5019D-4C-FN8TP User's Manual PCIe/PCI/PnP Configuration  PCIe/PCI/PnP Configuration  The following information will display: • PCI Bus Driver Version • PCI Devices Common Settings: Above 4G Decoding (Available if the system supports 64-bit PCI decoding) Select Enabled to decode a PCI device that supports 64-bit in the space above 4G Address.
  • Page 73 Chapter 6: UEFI BIOS VGA Priority Use this feature to select VGA priority when multiple VGA devices are detected. Select On- board to give priority to your onboard video device. Select Offboard to give priority to your graphics card. The options are Onboard and Offboard. CPU SLOT6 PCI-E 3.0 X16 OPROM Use this feature to select which firmware type to be loaded for the add-on card in this slot.
  • Page 74 SuperServer 5019D-4C-FN8TP User's Manual Network Stack Configuration Network Stack Select Enabled to enable PXE (Preboot Execution Environment) or UEFI (Unified Extensible Firmware Interface) for network stack support. The options are Enabled and Disabled. *If the feature above is set to Enabled, the next six features will be available for...
  • Page 75 Chapter 6: UEFI BIOS Change Settings This feature specifies the base I/O port address and the Interrupt Request address of Serial Port 1. Select Auto for the BIOS to automatically assign the base I/O and IRQ address to a serial port specified. The options are Auto, (IO=3F8h; IRQ=4), (IO=3F8h; IRQ=3, 4, 5, 6, 7, 9, 10, 11, 12), (IO=2F8h;...
  • Page 76 SuperServer 5019D-4C-FN8TP User's Manual Console Redirection Settings  Terminal Type This feature allows the user to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set. Select VT100+ to add color and function key support. Select ANSI to use the Extended ASCII Character Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
  • Page 77 Chapter 6: UEFI BIOS Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Disabled and Enabled. Legacy OS Redirection Resolution Use this feature to select the number of rows and columns used in Console Redirection for legacy OS support. The options are 80x24 and 80x25. Putty KeyPad This feature selects Function Keys and KeyPad settings for Putty, which is a terminal emulator designed for the Windows OS.
  • Page 78 SuperServer 5019D-4C-FN8TP User's Manual Data Bits Use this feature to set the data transmission size for Console Redirection. The options are 7 (Bits) and 8 (Bits). Parity A parity bit can be sent along with regular data bits to detect data transmission errors.
  • Page 79 Chapter 6: UEFI BIOS Redirection After BIOS POST Use this feature to enable or disable legacy console redirection after BIOS POST. When set to BootLoader, legacy console redirection is disabled before booting the OS. When set to Always Enable, legacy console redirection remains enabled when booting the OS. The options are Always Enable and BootLoader.
  • Page 80 SuperServer 5019D-4C-FN8TP User's Manual Bits per second This feature sets the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines. The options are 9600, 19200, 57600, and 115200 (bits per second).
  • Page 81 This feature displays the status of the TPM support on this motherboard. • TPM Enabled Status • TPM Active Status • TPM Owner Status SMCI BIOS-Based TPM Provision Support Use feature to enable the Supermicro TPM Provision support. The options are Disabled and Enabled.
  • Page 82 SuperServer 5019D-4C-FN8TP User's Manual TXT Support Intel TXT (Trusted Execution Technology) helps protect against software-based attacks and ensures protection, confidentiality and integrity of data stored or created on the system. Use this feature to enable or disable TXT Support. The options are Disabled and Enabled.
  • Page 83 Use this feature to disable or enable Platform Hiearchy (PH) Randomization. The options are Disabled and Enabled. SMCI BIOS-Based TPM Provision Support Use feature to enable the Supermicro TPM Provision support. The options are Disabled and Enabled. TXT Support Intel TXT (Trusted Execution Technology) helps protect against software-based attacks and ensures protection, confidentiality and integrity of data stored or created on the system.

  • Page 84: Event Logs

    SuperServer 5019D-4C-FN8TP User's Manual 6.4 Event Logs Use this menu to configure event log settings. Change SMBIOS Event Log Settings Enabling/Disabling Options SMBIOS Event Log Change this feature to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 85 Chapter 6: UEFI BIOS When Log is Full Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full. Select Do Nothing for the system to do nothing when the SMBIOS event log is full.

  • Page 86: Ipmi

    SuperServer 5019D-4C-FN8TP User's Manual 6.5 IPMI Use this menu to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This feature indicates the IPMI firmware revision in your system. IPMI STATUS This feature indicates the status of the IPMI firmware installed in your system.
  • Page 87 Chapter 6: UEFI BIOS Erase SEL Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot. The options are No, Yes, On next reset, and Yes, On every reset.
  • Page 88 SuperServer 5019D-4C-FN8TP User's Manual Subnet Mask This feature displays the sub-network that this computer belongs to. The value of each three-digit number separated by dots should not exceed 255. Station MAC Address This feature displays the Station MAC address for this computer. Mac addresses are 6 two-digit hexadecimal numbers.

  • Page 89: Security

    The Disable option is for applications that require faster power on time wthout using Supermicro Update Manager (SUM) or extended IPMI features. The BMC network configuration in the BIOS setup is also invalid when IPMI Function Support is disabled.
  • Page 90 SuperServer 5019D-4C-FN8TP User's Manual Password Check Select Setup for the system to check for a password at Setup. Select Always for the system to check for a password at bootup or upon entering the BIOS Setup utility. The options are Setup and Always.
  • Page 91 Chapter 6: UEFI BIOS  Enroll Efi Image This feature allows the image to run in Secure Boot mode. Device Guard Ready  Remove 'UEFI CA' from DB Use this feature to remove the Microsoft UEFI CA certificate from the database. The options are Yes and No.
  • Page 92 SuperServer 5019D-4C-FN8TP User's Manual Delete Select Ok to remove the KEK and then the system will reset to Setup/Audit Mode.  Authorized Signatures Details Select this feature to view the details of the db. Export Select Yes to export a db from a file on an external media.
  • Page 93 Chapter 6: UEFI BIOS Update Select Yes to load a factory default dbt or No to load from a file on an external media. Append Select Yes to add the dbt from the manufacturer's defaults list to the existing dbt. Select No to load the dbt from a file.

  • Page 94: Boot

    SuperServer 5019D-4C-FN8TP User's Manual 6.7 Boot Use this menu to configure boot settings: Boot mode select Use this feature to select the boot mode. The options are LEGACY, UEFI, and DUAL. Legacy to EFI Support Select Enabled to boot EFI OS support after Legacy boot order has failed. The options are...
  • Page 95 Chapter 6: UEFI BIOS Fixed BOOT ORDER Priorities This option prioritizes the order of bootable devices that the system to boot from. Press <Enter> on each entry from top to bottom to select devices. • Boot Option #1 • Boot Option #2 •...

  • Page 96: Save & Exit

    SuperServer 5019D-4C-FN8TP User's Manual 6.8 Save & Exit Use this menu to configure save and exit settings. Save Options Discard Changes and Exit Select this option to quit the BIOS Setup without making any permanent changes to the system configuration and reboot the computer. Select Discard Changes and Exit from the Exit menu and press <Enter>.
  • Page 97 Chapter 6: UEFI BIOS Default Options Restore Defaults To set this feature, select Restore Optimized Defaults and press <Enter>. These are factory settings designed for maximum system performance but not for maximum stability. Save as User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <Enter>. This enables the user to save any changes to the BIOS setup for future use.
  • Page 98 SuperServer 5019D-4C-FN8TP User's Manual Appendix A BIOS Codes A.1 BIOS Error POST (Beep) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the bootup process.
  • Page 99 When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.
  • Page 100 Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 101 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 102 SuperServer 5019D-4C-FN8TP User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬...
  • Page 103 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 104 SuperServer 5019D-4C-FN8TP User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 105 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 106 SuperServer 5019D-4C-FN8TP User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원...
  • Page 107 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 108 SuperServer 5019D-4C-FN8TP User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial,...
  • Page 109 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 110 SuperServer 5019D-4C-FN8TP User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제...
  • Page 111 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 112 SuperServer 5019D-4C-FN8TP User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 113 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 114 SuperServer 5019D-4C-FN8TP User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다.
  • Page 115 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 116 SuperServer 5019D-4C-FN8TP User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 117 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 118 ‫حجم املوصل والقابس السليم. استخدام أي كابالت ومحوالت أخرى قد يتسبب يف عطل أو حريق. يحظر قانون السالمة لألجهزة الكهربائية واملعدات استخدام الكابالت املعتمدة‬ ‫ من قبل‬UL ‫ أو‬CSA ‫( والتي تحمل عالمة‬UL/CSA) ‫ مع أي معدات أخرى غري املنتجات املعنية واملحددة من قبل‬Supermicro.
  • Page 119 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...
  • Page 120 SuperServer 5019D-4C-FN8TP User's Manual Appendix C System Specifications Processors Single Intel® Xeon® D-2123IT SoC with a TDP of up to 60W embedded processor on the motherboard Chipset System on a Chip BIOS 512Mb AMI BIOS® SPI Flash BIOS Memory Supports up to 256 GB of ECC RDIMM or 512 GB of ECC LRDIMM DDR4 memory with speeds of up to 2133 MHz and up to 128 GB size at 1.2V in four slots...
  • Page 121 Appendix C: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55032 Class A, EN 61000-3-2/3-3, CISPR 32 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11), CNS14336-1, CNS13438, GB4943.1-2011, GB9254-2008(Class A) and GB17625.1-2012 Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe) Other: VCCI-CISPR 32 and AS/NZS CISPR 32 Environmental: Directive 2011/65/EU and Delegated Directive (EU) 2015/863 and Directive 2012/19/EU...
  • Page 122 Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 123 Directory of a USB device or a writeable CD/DVD. Note: If you cannot locate the "Super.ROM" file in your driver disk, visit our website at www.supermicro.com to download the BIOS image into a USB flash device and rename it "Super.ROM" for BIOS recovery use.
  • Page 124 SuperServer 5019D-4C-FN8TP User's Manual 4. After locating the new BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
  • Page 125 Appendix D: UEFI BIOS Recovery 6. After the BIOS recovery process is completed, press any key to reboot the system. 7. Using a different system, extract the BIOS package into a USB flash drive. 8. Press <Del> continuously to enter the BIOS setup utility. Set the item, Boot Option #1, to [UEFI AP:UEFI: Built-in EFI Shell].
  • Page 126 SuperServer 5019D-4C-FN8TP User's Manual 9. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory which contains the BIOS package extracted earlier from Step 7. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process.
  • Page 127 Appendix E: Dual Boot Block Appendix E Dual Boot Block E.1 Introduction This motherboard supports the Dual Boot Block feature, which is the last-ditch mechanism to recover the BIOS boot block. This section provides an introduction to the feature. BIOS Boot Block A BIOS boot block is the minimum BIOS loader required to enable necessary hardware components for the BIOS crisis recovery flash that will update the main BIOS block.
  • Page 128 SuperServer 5019D-4C-FN8TP User's Manual E.2 Steps to Reboot the System by Using Jumper JBR1 1. Power down the system. 2. Close pins 2-3 on jumper JBR1 and power on the system. 3. Follow the BIOS recovery SOP listed in the previous chapter (Appendix D).
