  • Page 1 UpER ERvER 5019C-L 5019C-FL USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Warnings Special attention should be given to the following symbols used in this manual.

  • Page 4: Table Of Contents

    SuperServer 5019C-L/FL User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features ........................9 1.4 Chassis Features .......................10 Control Panel ........................10 Front Features ........................11 Chassis Rear ........................12 1.5 Motherboard Layout ......................13 Quick Reference .......................14 System Block Diagram ......................15 1.6 Where to Get Replacement Components ................16 1.7 Returning Merchandise for Service ..................16...
  • Page 5 Contents 3.3 Motherboard Components ....................24 Processor and Heatsink Installation ..................24 Installing the LGA 1151 Processor ................24 Installing the CPU Heatsink ..................27 Memory ..........................29 Memory Support ......................29 General Guidelines for Optimizing Memory Performance ..........29 DIMM Installation ......................31 Motherboard Battery ......................32 3.4 Chassis Components ......................33 Storage Drives ........................33 PCI Expansion Cards .......................35 System Fans ........................36...
  • Page 6 SuperServer 5019C-L/FL User's Manual Chapter 6 BIOS 6.1 Introduction .........................55 Starting BIOS Setup Utility ....................55 6.2 Main Setup .........................55 6.3 Advanced Settings Menu ....................57 6.4 Event Logs .........................79 6.5 IPMI ............................81 6.6 Security Settings ........................84 6.7 Boot Settings ........................88 6.8 Save & Exit .........................91 Appendix A BIOS Error Codes Appendix B Standardized Warning Statements for AC Systems Appendix C System Specifications...
  • Page 7 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 8: Chapter 1 Introduction

    SuperServer 5019C-L/FL User's Manual Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the 5019C-L/FL servers, based on the X11SCL-iF motherboard and the SC504-203B or SC505-203B chassis. The 5019C-L server has input/output ports in the rear, and the 5019C-FL in the front. In addition to the motherboard and chassis, several important parts that are included with the system are listed below.

  • Page 9: System Features

    Chapter 1: Introduction 1.3 System Features The following table is an overview of the main features of the 5019C-L/FL server. System Features Motherboard X11SCL-iF Chassis 5019C-L uses SC504-203B; 5019C-FL uses SC505-203B Intel Xeon E-2100, 8th Generation Core i3, Pentium, or Celeron series (in Socket Socket H4 - LGA 1151) with a thermal design power (TDP) of up to 95W and six cores Memory Up to 64 GB of unbuffered (UDIMM) DDR4 (288-pin) ECC memory with speeds of up to 2666 MHz in two...

  • Page 10: Chassis Features

    SuperServer 5019C-L/FL User's Manual 1.4 Chassis Features Control Panel Power switches and status LEDs are located on the control panel on the front of the chassis. Figure 1-1. Control Panel Control Panel Features Item Features Description Information LED Alerts operator to several states, as noted in the table below NIC2 LED Indicates network activity on LAN port 2 when flashing NIC1 LED...

  • Page 11: Front Features

    Chapter 1: Introduction Front Features The illustration below shows the features included on the front of the chassis. Figure 1-2. 5019C-L (SC504) Chassis Front View Figure 1-3. 5019C-FL (SC505) Chassis Front View Front Chassis Features Item Feature Description Control Panel Front control panel with LEDs and buttons (see preceding page) I/O Ports Input/Output ports (see next page and Section 4.3 for details)

  • Page 12: Chassis Rear

    SuperServer 5019C-L/FL User's Manual Chassis Rear The illustration below shows the features included on the rear of the chassis. Power supply modules display status lights. Figure 1-4. 5019C-L (SC504) Rear View Chassis Rear Features Item Features Description Power Supply Fixed internal module I/O Panel SC504 Rear I/O ports (see below and Section 4.3) PCI Slot...

  • Page 13: Motherboard Layout

    Chapter 1: Introduction 1.5 Motherboard Layout Below is a layout of the X11SCL-iF motherboard with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4. USB4/5 IPMI_LAN COM1...

  • Page 14: Quick Reference

    SuperServer 5019C-L/FL User's Manual Quick Reference Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) JPG1 VGA Enable Pins 1-2 (Enabled) JPL1, JPL2 LAN1, LAN2 Enable Pins 1-2 (Enabled) JPME2 ME Manufacturing Mode Pins 1-2 (Normal) JWD1 Watchdog Timer Pins 1-2 (Reset) Connector Description Onboard Battery...

  • Page 15: System Block Diagram

    Chapter 1: Introduction Description State: Status LED2 BMC Heartbeat LED Blinking Green: BMC Normal LED3 Onboard Power LED Solid Green: Power On LED4 Unit Identifier (UID) LED Solid Blue: Unit Identified LED5 CATERR LED Solid Orange: System CATERR System Block Diagram SVID IMVP8 VR DDR4 (CHA)

  • Page 16: Where To Get Replacement Components

    For faster service, RMA authorizations may be requested online (http://www.supermicro.com/ support/rma/). Whenever possible, repack the chassis in the original Supermicro carton, using the original packaging material. If these are no longer available, be sure to pack the chassis securely, using packaging material to surround the chassis so that it does not shift within the carton and become damaged during shipping.

  • Page 17: Chapter 2 Server Installation

    SuperServer 5019C-L/FL User's Manual Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.

  • Page 18: Server Precautions

    Chapter 2: Server Installation Server Precautions • Review the electrical and general safety precautions in Appendix B. • Determine the placement of each component in the rack before you install the rails. • Install the heaviest server components at the bottom of the rack first and then work your way up.

  • Page 19: Reliable Ground

    SuperServer 5019C-L/FL User's Manual Reliable Ground A reliable ground must be maintained at all times. To ensure this, the rack itself should be grounded. Particular attention should be given to power supply connections other than the direct connections to the branch circuit (i.e. the use of power strips, etc.). To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to ensure that the system remains stable.

  • Page 20: Installing The System Into A Rack

    Chapter 2: Server Installation 2.3 Installing the System Into a Rack This section provides information on installing the 5019C-L/FL system into a rack. The chassis has two rack mounting "ear" brackets, which are located on each side of the front of the chassis. To mount the system into a rack, screw these brackets directly to the front of the rack, two screws for each bracket.

  • Page 21: Installing The Server Into A Telco Rack

    SuperServer 5019C-L/FL User's Manual Installing the Server into a Telco Rack If you are installing the system into a two post (Telco) rack, follow the directions given on the previous pages for rack installation. The only difference in the installation procedure will be the positioning of the rack brackets to the rack.

  • Page 22: Chapter 3 Maintenance And Component Installation

    SuperServer 5019C-L/FL User's Manual Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 23: Accessing The System

    Chapter 3: Maintenance and Component Installation 3.2 Accessing the System The SC504/505 chassis feature a removable top cover to allow access to components inside. Removing the Top Cover 1. Remove the five screws that hold the chassis cover in place. There are two screws on each side of the chassis, and one screw on the back.

  • Page 24: Motherboard Components

    (gold contacts). Improper installation or socket misalignment can cause serious damage to the processor or CPU socket, which may require manufacturer repairs. • Refer to the Supermicro website for updates on processor support. • Graphics in this manual are for illustration only. Your components may look different.
  • Page 25 Chapter 3: Maintenance and Component Installation 2. Gently lift the load lever to open the load plate. Remove the plastic protective cover. Do not touch the CPU socket contacts. 3. Locate the triangle on the CPU and CPU socket, which indicates the location of Pin 1. Holding the CPU by the edges with your thumb and index finger, align the triangle on the CPU with the triangle on the socket.
  • Page 26 SuperServer 5019C-L/FL User's Manual 5. Close the load plate, then gently push down the load lever into its locking position. CPU properly installed Load lever locked into place Note: You can only install the CPU in one direction. Make sure it is properly inserted into the socket before closing the load plate.

  • Page 27: Installing The Cpu Heatsink

    Chapter 3: Maintenance and Component Installation Installing the CPU Heatsink Notes: • If you bought a CPU separately, use an Intel-certified multi-directional heatsink only. • Do not apply any thermal grease to the heatsink or the CPU die; the required amount has already been applied.
  • Page 28 SuperServer 5019C-L/FL User's Manual Removing a Heatsink We do not recommend removing the heatsink. If necessary, please follow the instructions below to prevent damage to the CPU or the CPU socket. 1. Unscrew and remove the heatsink screws from the motherboard in the sequence as show in the figure below.

  • Page 29: Memory

    Chapter 3: Maintenance and Component Installation Memory Note: Check the Supermicro website for recommended memory modules. Memory Support The X11SCL-iF supports up to 64 GB of unbuffered (UDIMM) DDR4 (288-pin) ECC memory (1-DIMM per channel) with speeds of up to 2666 MHz in two memory slots. Refer to the tables below for the recommended DIMM population order and additional memory information.
  • Page 30 SuperServer 5019C-L/FL User's Manual LED4 COM1 Intel i210 USB4/5 ASpeed (3.0) AST2500 IPMI LAN LAN1/2 USB0/1 X11SCL-IF LED2 REV:1.01 DESIGNED IN USA JPL1 JPL2 JPG1 LED5 JWD1 BIOS LICENSE JPME2 LED3 JLED1 I-SATA1 I-SGPIO1 Intel JSD1 C242 FAN1 FANA JTPM1 FAN2 USB8(3.0) JBT1...

  • Page 31: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation Insert the desired number of DIMMs into the memory slots based on the recommended population table on the previous page. Installing Memory Begin by removing power from the system as described in Section 3.1. 1.

  • Page 32: Motherboard Battery

    SuperServer 5019C-L/FL User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 33: Chassis Components

    The number of drives you choose to install may affect the number of expansion cards possible. Note: Enterprise level drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website product pages at https:// www.supermicro.com/products/nfo.
  • Page 34 SuperServer 5019C-L/FL User's Manual Figure 3-6. Four 2.5" Drives In Two Double Brackets, No Expansion Card Figure 3-7. One 3.5" Drives and One Low Profile Expansion Card Figure 3-8. Two 2.5" Drives and One Full-Height, Half-Length Expansion Card Figure 3-9. Two 3.5" Drives and No Expansion Card...

  • Page 35: Pci Expansion Cards

    Chapter 3: Maintenance and Component Installation PCI Expansion Cards The chassis includes a slot at the rear for an expansion card. The card is connected to the motherboard by means of a pre-installed riser card. Only certain storage drive configurations allow an expansion card: one 3.5"...

  • Page 36: System Fans

    SuperServer 5019C-L/FL User's Manual System Fans The system employs two fans in the default configuration. A third can be added using and optional kit. Note: A third fan is recommended if the system includes an M.2 card or other add-on card. The fans can adjust their speed according to the heat level sensed in the system, which results in more efficient and quieter fan operation.
  • Page 37 Chapter 3: Maintenance and Component Installation Figure 3-11. SC504-203B Installing Fans (showing optional third fan) Figure 3-12. SC505-203B Installing Fans (showing optional third fan)

  • Page 38: Installing The Air Shroud

    SuperServer 5019C-L/FL User's Manual Installing the Air Shroud Air shrouds concentrate airflow to maximize fan efficiency. It does not require screws to install. Installing the Air Shroud • Position the air shroud in the chassis as illustrated below. If necessary, move any cables that interfere with the air shroud placement.

  • Page 39: Checking The Server Air Flow

    Chapter 3: Maintenance and Component Installation SC505_X11SCL-IF Air Shroud Figure 3-15. Air Shroud Installed (SC505) Checking the Server Air Flow • Make sure there are no objects to obstruct airflow in and out of the server. • Do not operate the server without drives or drive carriers in the drive bays. •...

  • Page 40: Power Supply

    Power Supply This power supply can operate at an input voltage from 100 to 240 volts. If replacing it, use the exact same model. New units can be ordered directly from Supermicro or authorized distributors. Changing the Power Supply Module: 1.

  • Page 41: Chapter 4 Motherboard Connections

    Chapter 4: Motherboard Connections Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.

  • Page 42: Headers And Connectors

    TPM/Port 80 Header The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is available from Supermicro. TPM/Port 80 is a security device which supports encryption and authentication in hard drives. For more information, see: http://www.supermicro.com/manuals/ other/TPM.pdf.
  • Page 43 Chapter 4: Motherboard Connections Chassis Intrusion A Chassis Intrusion header is located at JL1 on the motherboard. Attach the appropriate cable from the chassis to inform you of a chassis intrusion when the chassis is opened. Chassis Intrusion Pin Definitions Pin# Definition Intrusion Input...
  • Page 44 The X11SCL-iF has four SATA 3.0 ports (I-SATA0 – I-SATA3) supported by the Intel C242 chipset. They support RAID 0, 1, 5, and 10. Note: Supermicro SuperDOMs are yellow SATADOM connectors with power pins built in and do not require separate external power cables. These connectors are backwards compatible with non-Supermicro SATADOMS that require an external power supply.

  • Page 45: Front Control Panel

    Chapter 4: Motherboard Connections Front Control Panel JF1 contains header pins for various control panel connections. Refer to the figure below for the pin locations and definitions of the control panel buttons and LED indicators. All JF1 wires have been bundled into a single cable to simplify this connection. Verify that the red wire plugs into pin 1 as marked on the motherboard.
  • Page 46 SuperServer 5019C-L/FL User's Manual Power Fail LED The Power Fail LED connection is located on pins 5 and 6 of JF1. Refer to the table below for pin definitions. Power Fail LED Pin Definitions (JF1) Pin# Definition 3.3V PWR Supply Fail Overheat (OH)/Fan Fail LED Connect an LED cable to pins 7 and 8 of the Front Control Panel to use the Overheat/Fan Fail LED connections.
  • Page 47 Chapter 4: Motherboard Connections Power LED The Power LED connection is located on pins 15 and 16 of JF1. Refer to the table below for pin definitions. Power LED Pin Definitions (JF1) Pins Definition 3.3V PWR LED NMI Button The non-maskable interrupt (NMI) button header is located on pins 19 and 20 of JF1. Refer to the table below for pin definitions.

  • Page 48: Ports

    Note: UID can also be triggered via IPMI on the motherboard. For more information on IPMI, refer to the IPMI User's Guide posted on our website: http://www.supermicro.com. Universal Serial Bus (USB) Ports There are two USB 2.0 ports (USB0/1) and two USB 3.1 Gen 1 ports (USB4/5) located on...

  • Page 49: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 50 SuperServer 5019C-L/FL User's Manual ME Manufacturing Mode Close pins 2-3 of jumper JPME2 to bypass SPI flash security and force the system to operate in the manufacturing mode, which will allow the user to flash the system firmware from a host server for system setting modifications.

  • Page 51: Led Indicators

    Chapter 4: Motherboard Connections 4.5 LED Indicators LAN LEDs Two Ethernet LAN ports (LAN 1, LAN 2) are located on the I/O panel (front or rear). Each port has two LEDs. One LED indicates activity when flashing amber. The other LED may be green, amber or off to indicate the speed of the connection.

  • Page 52: Chapter 5 Software

    You must first configure RAID settings (if using RAID) before you install the Windows OS and the software drivers. To configure RAID settings, please refer to the RAID Configuration User Guides posted on our website at www.supermicro.com/support/manuals. Installing the Windows OS for a RAID System 1.

  • Page 53: Driver Installation

    Chapter 5: Software 5.2 Driver Installation The Supermicro web site contains drivers and utilities for your system at https://www. supermicro.com/wftp/drivers. Some of these must be installed, such as the chipset driver. After accessing the web site, go into the CDR_Images directory and locate the ISO file for your motherboard.

  • Page 54: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 55: Chapter 6 Bios

    Chapter 6: BIOS Chapter 6 BIOS 6.1 Introduction This chapter describes the AMI BIOS setup utility for the X11SCL-iF and provides the instructions on navigating the setup screens. The BIOS is stored in a Flash EEPROM and can be updated. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted since this manual was published.
  • Page 56 HH:MM:SS format. Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2016 after RTC reset. Supermicro X11SCL-iF BIOS Version Build Date (of the BIOS) CPLD (Complex Programmable Logic Device) Version: This item displays the CPLD version used in the system.

  • Page 57: Advanced Settings Menu

    Chapter 6: BIOS 6.3 Advanced Settings Menu Use the arrow keys to select the Advanced submenu and press <Enter> to access the submenu items: Warning: Take Caution when changing the Advanced settings. An incorrect value, an incorrect DRAM frequency, or an incorrect BIOS timing setting may cause the system to malfunction. When this occurs, restore the setting to the manufacture default setting.
  • Page 58 SuperServer 5019C-L/FL User's Manual Bootup NumLock State Use this feature to set the Power-on state for the <Numlock> key. The options are On and Off. Option ROM Messages Use this feature to set the display mode for the Option ROM. Select Keep Current to display the current AddOn ROM setting.
  • Page 59 Chapter 6: BIOS CPU Configuration  The following CPU information will display: • Type • CPU Signature • Microcode Revision • CPU Speed • L1 Data Cache • L1 Instruction Cache • L2 Cache • L3 Cache • L4 Cache •...
  • Page 60 SuperServer 5019C-L/FL User's Manual Intel (VMX) Virtualization Technology Use this feature to enable the Vanderpool Technology. This technology allows the system to run several operating systems simultaneously. The options are Disabled and Enabled. Active Processor Cores This feature determines how many CPU cores will be activated for each CPU. When All is selected, all cores in the CPU will be activated.
  • Page 61 Chapter 6: BIOS Monitor/Mwait Select Enabled to enable the Monitor/Mwait instructions. The Monitor instructions monitor a region of memory for writes, while MWait instructions instruct the CPU to stop until the moni- tored region begins to write. The options are Disabled and Enabled. C-States C-State architecture, a processor power management platform developed by Intel, can further reduce power consumption from the basic C1 (Halt State) state that blocks clock cycles to...
  • Page 62 SuperServer 5019C-L/FL User's Manual System Agent (SA) Configuration The following information is displayed: • SA PCIe Code Version • VT-d  Memory Configuration • Memory RC Version • Memory Frequency • Memory Timings (tCL-tRCD-tRP-tRAS) • DIMMA1 ~ DIMMB1 information Maximum Memory Frequency Use this feature to set the maximum memory frequency for onboard memory modules.
  • Page 63 Chapter 6: BIOS DMI/OPI Configuration  The following DMI information will display: • DMI Link ASPM Control Use this feature to set the Active State Power Management (ASPM) state on the System Agent (SA) side of the DMI Link. The options are Disabled, L0s, L1, and L0sL1 DMI Extended Sync Control Use this feature to enable or disable the DMI extended synchronization.
  • Page 64 SuperServer 5019C-L/FL User's Manual Max Payload Size Select Auto for the system BIOS to automatically set the maximum payload value for a PCI-E device to enhance system performance. The options are Auto, 128, and 256 TLP. Program PCIe ASPM After OPROM PCIe ASPM, the Active State Power Management for PCI-Express slots, is a power management protocol used to manage power consumption of serial-link devices installed on PCI-E slots during a prolonged off-peak time.
  • Page 65 Chapter 6: BIOS Peer Memory Write Enable Use this feature to enable or disable peer memory write. The options are Disabled or Enabled.  M.2-H M.2-F ASPM Support This feature controls the Active State Power Management (ASPM) setting. The op- tions are Disabled, L0s, L1, L0sL1, and Auto.
  • Page 66 SuperServer 5019C-L/FL User's Manual Change Settings This feature specifies the base I/O port address and the Interrupt Request address of a serial port specified by the user. Select Auto to allow the BIOS to automatically assign the base I/O and IRQ address. The options for Serial Port 1 are Auto, (IO=3F8h;...
  • Page 67 Chapter 6: BIOS VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes. The options are VT100, VT100+, VT-UTF8, and ANSI. Bits Per Second Use this feature to set the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer.
  • Page 68 SuperServer 5019C-L/FL User's Manual Legacy OS Redirection Resolution Use this feature to select the number of rows and columns used in Console Redirection for legacy OS support. The options are 80x24 and 80x25. Putty KeyPad This feature selects the settings for Function Keys and KeyPad used for Putty, which is a terminal emulator designed for the Windows OS.
  • Page 69 Chapter 6: BIOS Parity A parity bit can be sent along with regular data bits to detect data transmission errors. Select Even if the parity bit is set to 0, and the number of 1's in data bits is even. Select Odd if the parity bit is set to 0, and the number of 1's in data bits is odd.
  • Page 70 SuperServer 5019C-L/FL User's Manual Legacy Console Redirection Legacy Console Redirection Settings Legacy Redirection COM Port Use this feature to select a COM port to display redirection of Legacy OS and Legacy OPROM messages. The options are COM1 and SOL. Legacy OS Redirection Resolution Use this feature to select the number of rows and columns used in Console Redirection for legacy OS support.
  • Page 71 Chapter 6: BIOS EMS Bits Per Second This feature sets the transmission speed for a serial port used in Console Redirection. Make sure that the same speed is used in the host computer and the client computer. A lower transmission speed may be required for long and busy lines. The options are 9600, 19200, 57600, and 115200 (bits per second).
  • Page 72 SuperServer 5019C-L/FL User's Manual Serial ATA Port 0 ~ Port 3 This feature displays the information detected on the installed SATA drive on the particular SATA port. • Model number of drive and capacity • Software Preserve Support Port 0 ~ Port 3 Hot Plug Set this feature to Enabled for hot plug support, which will allow the user to replace a SATA drive without shutting down the system.
  • Page 73 Chapter 6: BIOS High Precision Event Timer Select Enabled to activate the High Precision Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in synchronizing multimedia streams, providing smooth playback and reducing the dependency on other timestamp calculation devices, such as an x86 RDTSC Instruction embedded in the CPU.
  • Page 74 SuperServer 5019C-L/FL User's Manual PCIe/PCI/PnP Configuration  Option ROM Execution PCI PERR/SERR Support Select Enabled to allow a PCI device to generate a PERR/SERR number for a PCI Bus Signal Error Event. The options are Disabled and Enabled. Above 4GB MMIO BIOS Assignment Select Enabled to decode a PCI device that supports 64-bit in the space above 4G Address.
  • Page 75 Chapter 6: BIOS Onboard LAN1 ~ LAN2 Option ROM Use this feature to select which firmware function to be loaded for the specified onboard LAN port at system boot. The options are Disabled, PXE, and iSCSI*. *iSCSI is only supported on Onboard LAN1. The default setting for Onboard LAN1 is PXE.
  • Page 76 SuperServer 5019C-L/FL User's Manual Security Device Support If this feature and the TPM jumper on the motherboard are both set to Enable, onboard security devices will be enabled for TPM (Trusted Platform Module) support to enhance data integrity and network security. Please reboot the system for a change on this setting to take effect.
  • Page 77 TPM 2.0 will restrict support for TPM 2.0 devices. Select Auto to enable support for both versions. The options are TPM 1.2, TPM 2.0, and Auto. SMCI BIOS-Based TPM Provision Support Use feature to enable the Supermicro TPM Provision support. The options are Disabled and Enabled. TXT Support Intel Trusted Execution Technology (TXT) helps protect against software-based attacks and ensures protection, confidentiality, and integrity of data stored or created on the system.
  • Page 78 SuperServer 5019C-L/FL User's Manual  Add an Attempt  Delete Attempts  Change Attempt Order TLS Authentication Configuration  This submenu allows the user to configure Transport Layer Security (TLS) settings. Server CA Configuration Enroll Certification Enroll Certification Using File Use this feature to enroll certification from a file.

  • Page 79: Event Logs

    Chapter 6: BIOS 6.4 Event Logs Use this tab page to configure Event Log settings. Change SMBIOS Event Log Settings Enabling/Disabling Options SMBIOS Event Log Change this feature to enable or disable all features of the SMBIOS Event Logging during system boot.
  • Page 80 SuperServer 5019C-L/FL User's Manual SMBIOS Event Log Standard Settings Log System Boot Event This feature toggles the System Boot Event logging to enabled or disabled. The options are Enabled and Disabled. MECI The Multiple Event Count Increment (MECI) counter counts the number of occurences that a duplicate event must happen before the MECI counter is incremented.

  • Page 81: Ipmi

    Chapter 6: BIOS 6.5 IPMI Use this tab page to configure Intelligent Platform Management Interface (IPMI) settings. BMC Firmware Revision This item indicates the IPMI firmware revision used in your system. IPMI Status (Baseboard Management Controller) This item indicates the status of the IPMI firmware installed in your system. System Event Log Enabling/Disabling Options SEL Components...
  • Page 82 SuperServer 5019C-L/FL User's Manual to keep all system event logs after each system reboot. The options are No, Yes, On next reset, and Yes, On every reset. When SEL is Full This feature allows the user to decide what the BIOS should do when the system event log is full.
  • Page 83 Chapter 6: BIOS Subnet Mask This feature displays the sub-network that this computer belongs to. The value of each three- digit number separated by dots should not exceed 255. Station MAC Address This feature displays the Station MAC address for this computer. Mac addresses are 6 two- digit hexadecimal numbers.

  • Page 84: Security Settings

    SuperServer 5019C-L/FL User's Manual 6.6 Security Settings Use this tab page to configure Security settings. Password Check Select Setup for the system to check for a password at Setup. Select Always for the system to check for a password at bootup or upon entering the BIOS Setup utility. The options are Setup and Always.
  • Page 85 Chapter 6: BIOS Secure Boot Mode Use this feature to configure Secure Boot variables without authentication. The options are Standard and Custom. CSM Support Select Enabled to support the EFI Compatibility Support Module (CSM), which provides compatibility support for traditional legacy BIOS for system boot. The options are Disabled and Enabled.
  • Page 86 SuperServer 5019C-L/FL User's Manual Update Select Yes to load a factory default PK or No to load from a file on an external media. The options are Yes and No.  Key Exchange Keys Update Select Yes to load the KEK from the manufacturer's defaults. Select No to load the KEK from a file.
  • Page 87 Chapter 6: BIOS  OsRecovery Signature This feature uploads and installs an OSRecovery Signature. You may insert a factory default key or load from a file. The file formats accepted are: 1) Public Key Certificate a. EFI Signature List b. EFI CERT X509 (DER Encoded) c.

  • Page 88: Boot Settings

    SuperServer 5019C-L/FL User's Manual 6.7 Boot Settings Use this tab page to configure Boot Settings. Setup Prompt Timeout Use this feature to indicate the length of time (the number of seconds) for the BIOS to wait before rebooting the system when the setup activation key is pressed. Enter the value of 65535 (0xFFFF) for the BIOS to wait indefinitely.
  • Page 89 Chapter 6: BIOS • Legacy/UEFI/Dual Boot Option #5 • Legacy/UEFI/Dual Boot Option #6 • Legacy/UEFI/Dual Boot Option #7 • Legacy/UEFI/Dual Boot Option #8 • UEFI/Dual Boot Option #9 • Dual Boot Option #10 • Dual Boot Option #11 • Dual Boot Option #12 •...
  • Page 90 SuperServer 5019C-L/FL User's Manual Create Use this feature to set the name and the file path of the new boot option.  Add New Driver Option This feature allows the user to add a new EFI driver option to the driver order for your system.

  • Page 91: Save & Exit

    Chapter 6: BIOS 6.8 Save & Exit Use this tab page to configure Save & Exit settings. Save Options Discard Changes and Exit Select this feature to quit the BIOS Setup without making any permanent changes to the system configuration and reboot the computer. Select Discard Changes and Exit from the Save &...
  • Page 92 SuperServer 5019C-L/FL User's Manual Default Options Restore Defaults To set this feature, select Restore Defaults from the Save & Exit menu and press <Enter>. These are factory settings designed for maximum system stability, but not for maximum performance. Save As User Defaults To set this feature, select Save as User Defaults from the Save &...

  • Page 93: Appendix A Bios Error Codes

    When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 94: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 95 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 96 SuperServer 5019C-L/FL User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 97 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 98 SuperServer 5019C-L/FL User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 99 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 100 SuperServer 5019C-L/FL User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원 공급장치로부터...
  • Page 101 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 102 SuperServer 5019C-L/FL User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 103 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 104 SuperServer 5019C-L/FL User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 105 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 106 SuperServer 5019C-L/FL User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 107 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 108 SuperServer 5019C-L/FL User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 109 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 110 SuperServer 5019C-L/FL User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 111 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 112 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 113 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 114: Appendix C System Specifications

    Single Intel Xeon E-2100, 8th Generation Core i3, Pentium, or Celeron series in a Socket H4 - LGA 1151 design power (TDP) of up to 95W and six cores Note: Refer to the motherboard specifications pages on the Supermicro website for updates to supported processors. Chipset...
  • Page 115 Appendix C: System Specifications Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55032 Class A, EN 61000-3-2/3-3, CISPR 32 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Other: VCCI-CISPR 32 and AS/NZS CISPR 32 Environmental: Directive 2011/65/EU and Directive 2012/19/EU Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe)

  • Page 116: Appendix D Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 117 USB device or a writable CD/DVD. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 118 SuperServer 5019C-L/FL User Manual 3. After locating the healthy BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
  • Page 119 Appendix D: UEFI BIOS Recovery 5. After the BIOS recovery process is complete, press any key to reboot the system. 6. Using a different system, extract the BIOS package into a USB flash drive. 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu.
  • Page 120 SuperServer 5019C-L/FL User Manual 8. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory that contains the BIOS package you extracted earlier from Step 6. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process. Note: Do not interrupt this process until the BIOS flashing is complete.
