Quick Reference - Supermicro SuperServer 5019C-M4L User Manual

SuperServer 5019C-M4L User's Manual

Quick Reference

Jumper Description
JBT1 CMOS Clear
JPG1 VGA Enable
–
GLAN Enable
JPL1 JPL4
JPME2 ME Manufacturing Mode
JWD1 Watchdog Timer
Connector Description
COM1 COM Header
FAN1 – FAN4
CPU/System Fan Headers
FANA, FANB
IPMI_LAN Dedicated IPMI LAN Port
Intel PCH SATA 3.0 Ports (with RAID 0, 1, 5, 10)
I-SATA0 – I-SATA5
I-SATA4 and I-SATA5 supports SuperDOM
I-SGPIO1, I-SGPIO2 Serial Link General Purpose I/O Headers
JBAT1 Onboard Battery
Speaker Header
JD1
(Pins 1-4: Speaker; Pins 3-4: Onboard Buzzer)
JF1 Front Control Panel Header
JL1 Chassis Intrusion Header
JLED1 Onboard Power LED Header
JLD1 LAN3 – LAN4 Activity LED Connector
JLD2 LAN5 – LAN8 Activity LED Connector (not applicable in this system)
JPW1 24-pin ATX Power Supply Connector
JPW2 8-pin Power Connector
JSD1, JSD2 SATA DOM Power Connectors
JSTBY1 Standby Power Header
JTPM1 Trusted Platform Module (TPM)/Port 80 Header
JUIDB1 Unit Identifier (UID) Switch
LAN1 – LAN4 1GbE LAN Ports , LAN 1-4
M.2-H_2 M.2 Slot for PCI-E 3.0 x4 (Supports M-Key 2280 / 22110 and Intel Optane Memory)
SLOT6 CPU PCI-E 3.0 x16 Slot
SP1 Onboard Buzzer
USB0/1 Back Panel Universal Serial Bus (USB) 2.0 Ports
USB2/3 Front Accessible USB 2.0 Header
USB4/5 Back Panel USB 3.1 Gen 1 Ports
USB6/7 Front Accessible USB 3.1 Gen 1 Header
USB8 USB 3.1 Gen 1 Type-A Header
VGA VGA Port
Default Setting
Open (Normal)
Pins 1-2 (Enabled)
Pins 1-2 (Enabled)
Pins 1-2 (Normal)
Pins 1-2 (Reset)
14
