RTM-ATCA-F140-D Information
A.1
RTM-ATCA-F140-D Overview
The RTM-ATCA-F140-D is a rear transition module (RTM) used with the ATCA-F140-D
blade. The RTM features a Zone 3 attachment block and captive screw specifically
designed to securely attach the RTM to the front blade for operation in rugged
environments.
A.2
Mechanical
The following figure shows the location of the Zone 3 attachment block and the captive
screw, which secures the RTM to the front blade.
Figure A-1 Location of Zone 3 Attachment Block and Captive Screw
Zone 3
Attachment
Block
RTM-ATCA-F140 Series Installation and Use (6806800M97M)
RTM-ATCA-F140-D
Side View
Upper Handle
Captive Screw
Lower Handle
Appendix A
RTM-ATCA-F140-D
Front View
73
