1. On the front blade, slide the latch into the release position and pull the handle outward
to unlatch the handle from the face plate. Do not rotate the handle fully outward.
The front blade blue LED blinks indicating that the blade is powering down. Wait
until the front blade blue LED is illuminated permanently.
If the LED continues to blink, a possible reason may be that upper layer software
rejects the blade extraction request.
2. Remove face plate cables if needed.
3. Unfasten the screws of the RTM face plate until the RTM is detached from the shelf.
4. Unlatch the RTM handle and rotate fully outward.
5. Remove the blade from the shelf.
