Table 1-1
Standard
FCC 47 CFR Part 15 Subpart B
(US), Class A
GR-1089 - Ports and Intra-building
Lightning
GR-1089-CORE
GR63-CORE
IEC 62368-1 and 60950-1 CB
Scheme
NEBS Level 3
Safety Mark for U.S. and Canada
UL/CSA No. 62368-1 and 60950-1
VCCI Class A (Japan)
Verizon CHECKLIST
1.4

Mechanical Data

Table 1-2
Data
Dimensions
Weight
RTM-ATCA-F140 Series Installation and Use (6806800M97M)
Standard Compliance (continued)
Description
The product complies with FCC 47 CFR Part 15 Subpart B
(US), Class A.
All externally accessible ports shall be designed to comply with
the applicable GR-1089 requirements for Telecommunication
Ports.
Products are designed to comply with all applicable
requirements for Type 2 Equipment referenced in Telcordia
Document GR-1089-CORE.
The product is designed to comply with all applicable
requirements of Telcordia GR-63-CORE, NEBS
Requirements: Physical Protection.
The product complies with IEC 62368-1 and 60950-1 CB
Scheme including all National Deviations Safety of Information
Technology Equipment. Testing shall be by an accredited lab.
Module is designed to pass all testing to Criteria Level 3 per
Telcordia SR-3580.
The product is designed to certify to UL/CSA No. 62368-1 and
60950-1 with no deviations and shall bear the Recognition
Mark of an NRTL for US and Canada.
The product complies with UL/CSA 62368-1 and 60950-
1Safety of Information Technology Equipment.
The product complies with VCCI Class A (Japan), Voluntary
Control Council for Interference by Information Technology
Equipment.
The product is designed to comply with the latest version of the
Verizon Document VZ.NEBS.TE.NPI.2004.015: NEBS
Checklist.
RTM-ATCA-F140 Mechanical Data
Value
8U x 6 HP form factor - 3mm x 351mm x 143mm (including face plate
handles and alignment posts)
0.725Kg
Introduction
