4.6.5

BCM84740 Status

The LASI signal from the BCM84740 is individually connected to the RTM FPGA to allow it
to be monitored by software. The LASI signal can also generate an interrupt to the front
blade. Refer to
4.6.6

Fabric QSFP+ Connection

The QSFP+ cage accepts industry standard QSFP+ optical modules. It also accepts
QSFP+ copper and optical direct-attach cables. The site is designed to support power level
2 modules which are rated up to 2W (refer to the ATCA-F140 Installation and Use Manual
for a list of QSFP+ devices tested with this product). The QSFP+ connector assignment for
the 40Gbps serial interface is described in
Table 4-9
Pin
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
RTM-ATCA-F140 Series Installation and Use (6806800M97M)
GPS Connectors on page 67
QSFP+ Connector Pin Assignment
Signal
GND
TX2-
TX2+
GND
TX4-
TX4+
GND
MODSEL#
RESET#
VCCR (+3.3V)
I2C_SCL
I2C_SDA
GND
RX3+
RX3-
GND
RX1+
Functional Description
for further details.
Table 4-9.
Pin Signal
38 GND
37 TX1-
36 TX1+
35 GND
34 TX3-
33 TX3+
32 GND
31 LPMODE
30 VCC1 (+3.3V)
29 VCCT (+3.3V)
28 INT#
27 MODPRS#
26 GND
25 RX4+
24 RX4-
23 GND
22 RX2+
65
