GEIGER Engineering HPD12 Handbuch Manual page 55

Pin
# MOT-T2 Nr..
1
2
Pin
# ES Nr..
1
2
Pin
Nr..
# PM2-
Conn. 1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Motor Temp. 2 WR-MPC3-2p
Gnd
Temp. Mot.2 ; function to
parameterize
Emergency Stop WR-MPC3-2p
supply voltage 3,3V
Emergency off Input; ; function to
parameterize (P147)
Slavemodulconnector Sub-D
female 15pole
Gnd/Schirm
PM 2 Temp
TxD PM2
RxD PM2
Treiberpin UH
Treiberpin UL
Treiberpin VH
Treiberpin VL
Treiberpin WH
Treiberpin WL
not used
not used
not used
not used
+3,3V
Description
related GND
Motortemperature Sensor 1 (iron temperature)
Description
supply voltage for Emergency contact
Emergency off or disabling mc; P 147 refer to
parameter documentation
55
