GEIGER Engineering HPD12 Handbuch Manual page 54

Pin
# RJ45/RS485 Nr.:
1
2
3
4
5
6
7
8
# FAN Pin Nr..
1
2
3
4
#ENC/Hall Pin Nr..
1
2
3
4
5
6
# Isol. Pin Nr..
1
2
Pin
# MOT-T1 Nr..
1
2
RJ45/RS485 Battery
Communication
RS485 B
RS485 A
RS485 GND
not used
not used
not used
Tastersignal
Push on to slave
Fan WR-MPC3-4p
FAN - Out /batt-voltage @ 0,5A
max.
connected to PIN 3
connected to PIN 2
GND
Encoder WR-MPC3-6p
Encoder A / Hall U
Temp. Mot.1
Encoder B / Hall V
Encoder N / Hall W
+5V/max. 200mA
GND
Motor Isolation WR-MPC3-2p
Isol.
Isol.
Motor Temp.1 WR-MPC3-2p
Gnd
Temp. Mot.1
Description
RS485 Communicaton line to Interface and
Akku
RS485 Communicaton line to Interface and
Akku
On button signal 3,3V
On button signal battery voltage
Description
Fan activity controlled by Parameter 072; refer to
parameter documentation
internal connected
internal connected
GND for FAN
Description
Hallsensor for phase U detection
Motortemperature Sensor 1 (winding
temperature)
Hallsensor for phase V detection
Hallsensor for phase W detection
5V Supply for Hallsensors
GND for Hallsensors
Description
Isolations measurment pin
Isolations measurment pin
Description
related GND
Motortemperature Sensor 1 (winding
temperature)
54
