Onboard Serial Port B
Auto
3F8/COM1
2F8/COM2
3E8/COM3
2E8/COM4
Disabled
Serial Port B Mode
(This item allows you to determine which Infra Red(IR) function of Onboard I/O chip)
ASKIR
Set onboard I/O chip UART to ASKIR Mode.
IrDa
Set onboard I/O chip UART to IrDa Mode.
Normal
Set onboard I/O chip UART to Normal Mode. (Default Value)
IR Duplex Mode
Half Duplex
Full Duplex
OnBoard CIR Port
Disabled
Disable this function. (Default Value)
Enabled
Enable Onboard CIR port.
CIR IRQ Select
IRQ 3 / 4 / 9 / 10 (Default Value) / 11
Onboard Parallel Port
378
Set On Board LPT port and address to 378.
278
Set On Board LPT port and address to 278.
3BC
Set On Board LPT port and address to 3BC.
Auto
Set On Board LPT port Automatically. (Default Value)
Disabled
Disable onboard Serial port A.
BIOS will automatically setup the port B address. (Default Value)
Enable onboard Serial port B and address is 3F8.
Enable onboard Serial port B and address is 2F8.
Enable onboard Serial port B and address is 3E8.
Enable onboard Serial port B and address is 2E8.
Disable onboard Serial port B.
IR Function Duplex Half. (Default Value)
IR Function Duplex Full.
4 9
BIOS Setup
