GA-8ITX Series Motherboard

Parallel Port Mode

EPP
ECP
Normal
EPP Version
N/A
1.9
1.7

Parallel Port IRQ

7
5
Auto
Parallel Port DMA
3
1
0
Auto
OnBoard Midi Port**
Disabled
300
330
292
290
Midi IRQ Select**
IRQ 5 / 7 / 9 / 10 (Default Value)
"**" For GA-8ITX Only.
Using Parallel port as Enhanced Parallel Port.
Using Parallel port as Extended Capabilities Port. (Default Value)
Normal Operation.
Disable this function. (Default Value)
Compliant with EPP 1.9 version.
Compliant with EPP 1.7 version.
Set Parallel Port IRQ to 7.
Set Parallel Port IRQ to 5.
Set Parallel Port IRQ automatically. (Default Value)
Set Parallel Port DMA to 3.
Set Parallel Port DMA to 1.
Set Parallel Port DMA to 0.
Set Parallel Port DMA automatically. (Default Value)
Disable onboard Midi Port. (Default Value)
Set onboard Midi Port to 300.
Set onboard Midi Port to 330.
Set onboard Midi Port to 292.
Set onboard Midi Port to 290.
