R: Front Audio
H: Battery
+
If you want to use "Front Audio"
connector, you must move 11-12,13-14
Jumper.
In order to utilize the front audio header,
your chassis must have front audio
connector. Also please make sure the pin
assigment on the cable is the same as the
pin assigment on the MB header. To find
out if the chassis you are buying support
front audio connector, please contact
your dealer.
CAUTION
Danger of explosion if battery is incorrectly
replaced.
Replace only with the same or equivalent
type recommended by the manufacturer.
Dispose of used batteries according to the
manufacturer's instructions.
