GA-8ITX Series Motherboard

OnBoard IDE

Disabled
Both
Primary
Secondary Only Secondary IDE channel is enabled.
IDE1 Conductor Cable
Auto
ATA66/100
ATA33
IDE2 Conductor Cable
Auto
ATA66/100
ATA33
OnBoard FDC
Disabled
Enabled
Auto
Onboard Serial Port A
Auto
3F8/COM1
2F8/COM2
3E8/COM3
2E8/COM4
Disabled
Disable OnBoard IDE.
Both Primary & Secondary IDE channel will be enabled. (Default Value)
Only Primary IDE channel is enabled.
Will be automatically detected by BIOS. (Default Value)
Set IDE1 Conductor Cable to ATA66/100 (Please make sure your IDE device and
cable is compatible with ATA66/100).
Set IDE1 Conductor Cable to ATA33 (Please make sure your IDE device and
cable is compatible with ATA33).
Will be automatically detected by BIOS. (Default Value)
Set IDE2 Conductor Cable to ATA66/100 (Please make sure your IDE device and
cable is compatible with ATA66/100).
Set IDE2 Conductor Cable to ATA33 (Please make sure your IDE device and
cable is compatible with ATA33).
Disable this function.
Enable on board floppy disk controller.
Set the floppy disk controller automatically. (Default Value)
BIOS will automatically setup the port A address. (Default Value)
Enable onboard Serial port A and address is 3F8.
Enable onboard Serial port A and address is 2F8.
Enable onboard Serial port A and address is 3E8.
Enable onboard Serial port A and address is 2E8.
Disable onboard Serial port A.
