GA-8ITX Series Motherboard

Chapter 1 Introduction

Summary of Features

Form Factor
Motherboard
CPU
Chipset
Memory
I/O Control
Slots
On-Board IDE
On-Board Peripherals
Hardware Monitor
30.5cm x 24.5cm ATX size form factor, 6 layers PCB.
GA-8ITX Series Motherboard:
GA-8ITX and GA-8ITXR
®
Socket 478 for Intel
Intel Pentium ® 4 400MHz FSB
2nd Level cache depend on CPU
Chipset 82850 HOST/AGP/Controller
82801BA(ICH2) I/O Controller Hub
4 184-pin RIMM Sockets
Dual direct RDRAM channel
Supports up to 2GB (Max)
Winbond W83627HF
1 CNR(Communication and Networking Riser) Slot
1 AGP support 4X(1.5V) device
6 PCI slot supports 33MHz & PCI 2.2 compliant
An IDE controller on the Intel 82801BA PCI chipset
provides IDE HDD/CD-ROM with PIO, Bus Master (Ultra
DMA33/ATA66/ATA100) operation modes.
Can connect up to four IDE devices
1 Floppy port supports 2 FDD with 360K, 720K,1.2M, 1.44M
and 2.88M bytes.
1 Parallel port supports Normal/EPP/ECP mode
2 Serial ports (COMA&COMB)
4 USB ports (Rear USB x 2, Front USB x 2)
1 IrDA connector for IR/CIR
CPU/Power/System Fan Revolution detect
CPU Overheat Warning
System Voltage Detect
6
Micro FC-PGA2 Pentium
®
4 processor
to be continued......
