GA-8ITX Series Motherboard
Chipset Features Setup
( C ) 2001 American Megatrends, Inc. All Rights Reserved
Front Side Bus Clock (MHz)
CPU Frequency Ratio
RDRAM Bus Frequency
Vcore Voltage
Over RIMM Voltage
Over AGP Voltage
Memory ECC Mode
Graphics Aperture Size
ICH Delayed Transaction
DMA Collection Buffer
Front Side Bus Clock (MHz)
When set to "By Hardware", the FSB clock frequency will be set to 100MHz. You may also
set FSB clock by BIOS. For power End-User use only.
By Hardware
100.00
103.00
105.00
108.00
110.00
112.00
115.00
118.00
120.00
133.33
"*" For GA-8ITXR Only.
AMIBIOS SETUP - CHIPSET FEATURES SETUP
: By Hardware
: 8.0x(Safe)
: Auto
: Original*
: Disabled*
: 1.5V*
: Disabled
: 64MB
: Disabled
: Enabled
Figure 4: Chipset Features Setup
Set Front Side Bus Clock (MHz) to By Hardware. (Default Value)
Set Front Side Bus Clock (MHz) to 100.00.
Set Front Side Bus Clock (MHz) to 103.00.
Set Front Side Bus Clock (MHz) to 105.00.
Set Front Side Bus Clock (MHz) to 108.00.
Set Front Side Bus Clock (MHz) to 110.00.
Set Front Side Bus Clock (MHz) to 112.00.
Set Front Side Bus Clock (MHz) to 115.00.
Set Front Side Bus Clock (MHz) to 118.00.
Set Front Side Bus Clock (MHz) to 120.00.
Set Front Side Bus Clock (MHz) to 133.33.
ESC: Quit
F1 : Help
F5 : Old Values (Shift)F3: Select Language
F6 : Fail-Safe
F7 : Optimized
3 6
: Select Item
PU/PD+/-/ : Modify
F8: Flash Utility
