GA-8ITX Series Motherboard
M: Front USB Connector
GND
1
Power
O: TEL*
1
"*" For GA-8ITXR only.
Power
GND
P: AUX IN*
1
2 2
Be careful with the polarity of the front
panel USB connector. Check the pin
assignment while you connect the front
panel USB cable. Please contact your
nearest dealer for optional front panel
USB cable.
Q: CD IN
1
CD-R
GND
CD-L
