Expansion Interface - Analog Devices EZ-Extender ADSP-CM408 Series Manual

3
4
1
Figure 1-1. Mechanical Mating Details

This image shows the PWM 180-Pin Probing Board, but this is the
same attachment setup for the Analog 120-Pin Probing Board.

Expansion Interface

The expansion interface allows a custom-designed daughter board to be
tested across various hardware platforms that have the same expansion
interface.
The expansion interface implemented on the ADSP-CM40x EZ-KIT
Lites consists of two 180-pin connectors. The connectors contain a major-
ity of the processor's signals. There is also a 120-pin connector for Analog
signals. The Analog 120-Pin Probing Board should not be connected to
the 180-pin connectors.

Analog Devices does not support and is not responsible for the
effects of additional circuitry.
Analog 120-Pin Probing Board Manual
Using Analog 120-Pin Probing Board
3
1
Item Part Description
1 0.75in Nylon Standoff
2 1.0in Nylon Standoff
3 Steel Screw
Nylon Spacer
4
2
1-3
