Connector (J1); Connector (P1); Connector (P2-P5); Connector (P7-P14) - Analog Devices EZ-Extender ADSP-CM408 Series Manual

Analog 120-Pin Probing Board Hardware Reference

Connector (J1)

Part Description
120-pin high speed socket
120-pin high speed header

Connector (P1)

Part Description
120-pin high speed header
120-pin high speed socket
Connector (P2–P5)
Part Description
IDC 15x2 0.1"
0.1" female connector with wire or oscilloscope probe
Connector (P7–P14)
Part Description
IDC 2x1 0.1"
0.1" oscilloscope probe GND
Analog 120-Pin Probing Board Manual
Manufacturer
SAMTEC
Mating Connector
SAMTEC
Manufacturer
SAMTEC
Mating Connector
SAMTEC
Manufacturer
SAMTEC
Mating Connector
Manufacturer
FCI
Mating Connector
Part Number
QSH-060-01-F-D-A
QTH-060-01-F-D-A
Part Number
QTH-060-01-F-D-A
QSH-060-01-F-D-A
Part Number
TSW-115-07-L-D
Part Number
90726-402HLF
2-3
