Analog 120-Pin Probing Board Installation
Contact the vendor where you purchased your EZ-KIT Lite or contact
Analog Devices, Inc. if any item is missing.
Analog 120-Pin Probing Board
Installation
Follow these instructions to ensure correct operation of the product
hardware.
1. Attach the extender board to the EZ-KIT Lite.
The
connector on the extender board can be connected to the
P1
corresponding 120-pin connector on the EZ-KIT Lite.
2. Use the provided hardware to secure the extender to the EZ-KIT
Lite.
1-2
Analog 120-Pin Probing Board Manual
