A ANALOG 120-PIN PROBING
BOARD BILL OF MATERIALS
The bill of materials corresponds to
Schematic.
Ref. Qty Description
1 8 IDC 2X1 IDC2X1
2 1 0.5MM 120PIN SAMTEC_
QSH-060-F-D-A
3 1 0.5MM 120PIN SAMTEC_
QTH-060-F-D-A
4 4 IDC 15X2 SAMTEC_
TSW-115-07-L-D
Analog 120-Pin Probing Board Manual
Analog 120-Pin Probing Board
Reference Manufacturer
Designator
P7-P14 FCI
J1 SAMTEC
P1 SAMTEC
P2-P5 SAMTEC
Part Number
90726-402HLF
QSH-060-01-F-D-A
QTH-060-01-F-D-A
TSW-115-07-L-D
