PREFACE
Thank you for purchasing the Analog 120-Pin Probing Board, Analog
Devices, Inc. probing board for the ADSP-CM40x family of mixed-signal
control processors.
The ADSP-CM408F mixed-signal control processor is based on the
® ®
ARM Cortex -M4 processor core and is designed for motor control and
industrial applications. The probing board is shipped with all of the neces-
sary hardware—you can start the evaluation immediately.

Product Overview

The Analog 120-Pin Probing Board is a separately sold extender board
that plugs onto the ADSP-CM403F and ADSP-CM408F EZ-KIT Lite
evaluation systems. The extender board aids the design and prototyping
phases of processor-targeted applications.
The board extends the capabilities of the evaluation system by providing a
point for probing any signal of the 120-pin asynchronous bus and PWM
expansion interface connectors.
The board features:
• Two 120-pin connectors
• Samtec QSH-060-01-F-D-A
• Samtec QTH-060-01-F-D-A
