Purpose of This Manual

• Four probing headers
• Samtec TSW-115-07-L-D
• Eight GND headers
• FCI 90726-402HLF
For information about the hardware components of the product, refer to
Analog 120-Pin Probing Board Bill Of
Purpose of This Manual
The Analog 120-Pin Probing Board Manual provides instructions for
installing the product hardware (board). A schematic and a bill of materi-
als are provided for reference.

Intended Audience

The primary audience for this manual is a programmer who is familiar
with an ARM Cortex-M4-based core.
The ADSP-CM40x family of mixed-signal control processors is based on
the ARM Cortex-M4 processor core with floating-point unit and inte-
grated SRAM memory, flash memory, accelerators, and peripherals.
The applicable documentation for programming the ARM Cortex-M4
processor core includes:
• Cortex-M4 Devices Generic User Guide
• CoreSight ETM-M4 Technical Reference Manual
• Cortex-M4 Technical Reference Manual
