2 ANALOG 120-PIN PROBING
BOARD HARDWARE
REFERENCE
This chapter describes the hardware design of the Analog 120-Pin Probing
Board.
The following topics are covered.
•

System Architecture

Describes the board's configuration and explains how the board
components interface with the processor.
• Connectors
Shows the locations and provides part numbers for the on-board
connectors. In addition, the manufacturer and part number infor-
mation is provided for the mating parts.
System Architecture
The Analog 120-Pin Probing Board allows all signals to be probed.
Silkscreen on the board corresponds with the pin number of the
QTH-060-01-F-D-A (
one-to-one with the QSH-060-01-F-D-A (
attached EZ-KIT Lite.
It is also possible to connect the Analog 120-Pin Probing Board in
between the EZ-KIT Lite and an extender card with additional circuitry.
To do this, connect
the extender card to
Analog 120-Pin Probing Board Manual
) connector. These numbers also match
P1
of the extender card to the EZ-KIT Lite and attach
P1
of the Analog 120-Pin Probing Board.
J1
) connector located on the
Jx
2-1
