Once the outside antenna is secured to a pipe or pole, connect antenna to cable connector
of end of the length of cable and run along route to planned
location of your booster.
Nut
Drip Hole
Outdoor
Cable
IMPORTANT: For boosters enhancing AWS frequencies, the FCC has stated for consumer signal boosters
operating as a fixed station in the 1710 - 1755 MHz uplink 2110 - 2155 downlink bands, the users or
installation manual must contain the 30 foot height restriction requirements per FCC 27.50(d)(4).
IMPORTANT: Do not collocate antennas or operate the outdoor antenna with any other antenna or signal booster.
SureCall | 1-888-365-6283 | support@surecall.com | www.surecall.com
U-bolt
Washer
Bracket
Mounting
pole not
provided
Booster Installation
Antenna Aiming
OK
Outdoor Yagi
Outdoor
Cable
Planned
booster
location
9
