- Page 1 Fusion Install Cellular signal booster kit for the Home User Guide 02.07.2021...
- Page 2 Introduction Thank you for purchasing SureCall’s Fusion Install cellular signal booster kit. SureCall’s Fusion Install was specifically designed to eliminate frustrations over dropped calls and limited range by amplifying incoming and outgoing cellular signals in homes and offices. If you have any questions during setup, please reach out to our US-based experienced support technicians: Call: 1-888-365-6283 Email: support@surecall.com...
-
Page 3: Table Of Contents
Check and Optimize System, if Needed ..................10 TROUBLESHOOTING ........................10 LED INDICATORS ..........................11 SPECIFICATIONS ..........................12 Kitting .............................. 12 CONSUMER GUIDELINES ........................ 14 WARRANTY ............................15 Three-Year Product Warranty ......................15 SureCall, Inc | 1-888-365-6283 | support@surecall.com | www.surecall.com... -
Page 4: How It Works
The system also works in reverse amplifying outgoing signal back to the tower. Outside Antenna Coax Cable (50 ft) Inside Antenna Coax Cable (20 ft) Signal Booster Power Supply How the SureCall Fusion Install Booster Works SureCall, Inc | 1-888-365-6283 | support@surecall.com | www.surecall.com... -
Page 5: Package Contents
(20 ft) Warning: Changes or modifications not expressly approved by SureCall could void the user’s authority to operate the equipment. FCC 15.105 Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 6: Before Installation
A signal of -120 dB indicates you have no service, while a score of about -50 dB means you have excellent signal strength Signal Strength Poor Good Excellent SureCall, Inc | 1-888-365-6283 | support@surecall.com | www.surecall.com... -
Page 7: Step 2. Install The Outside Antenna
Run the cable along route to planned location of your booster. Washer U-bolt Bracket Drip Hole Warning: Do not collocate antennas or operate the outdoor antenna with any other antenna RG-11 Cable or signal booster. Yagi Antenna Assembly SureCall, Inc | 1-888-365-6283 | support@surecall.com | www.surecall.com... -
Page 8: Step 3. Install The Booster And Inside Antenna
Caution: Do Not aim antennas towards one another. SureCall’s Inside panel antennas are directional with a 120˚ reach. They should be mounted facing the area signal is needed and away from the outdoor antenna (See “Aiming Antennas”). Mount on a vertical surface that is the approximate height of normal cell phone use. The antenna may be concealed behind a wall provided there are no materials that could obstruct signals. -
Page 9: Step 4: Connect To Power And Turn On
Note: This booster is rated for 5-15V input voltage. DO NOT use the booster with a higher voltage power supply. This can damage the booster, cause personal injury, and void your warranty. This booster should not be used near open fire or flame. Storage and transportation: Store and place in non-extreme room-temperature and dry environment. SureCall, Inc | 1-888-365-6283 | support@surecall.com | www.surecall.com... -
Page 10: Check And Optimize System, If Needed
Verify that the power source is not controlled by a switch that has removed power from the outlet. If it remains OFF, contact tech support at: 1-888-365-6283 or support@surecall.com After completing Verify that cable connections are tightly fitted to the booster and antennas. -
Page 11: Led Indicators
The gain dials on the booster should always be at maximum level unless a control light is flashing red-yellow. Additionally, they should only be reduced if other recommended actions do not resolve the issue. Visit www.surecall.com/support to download the user manual for additional information. -
Page 12: Specifications
3 dBi / 3 dBi SC-302W 2.5 dBi 2.5 dBi 3 dBi 5 dBi 4 dBi / 5 dBi * All equivalent antennas and cables are suitable for use with the Fusion4Home 3.1 SureCall, Inc | 1-888-365-6283 | support@surecall.com | www.surecall.com... - Page 13 60.4 Warning: Any product modifications that use unauthorized antennas, cables, and/or coupling devices are prohibited by the FCC. Contact FCC for details: 1-888-CALL-FCC. Changes or modifications not expressly approved by SureCall could void the user’s authority to operate the equipment.
-
Page 14: Consumer Guidelines
à la sortie du dispositif. 1 For details on the requirements specified in ISED CPC-2-1-05, visit: http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08942.html 2 Pour plus de détails sur les exigences ISED CPC-2-1-05, reportez-vous au site: http://www.ic.gc.ca/eic/site/smt-gst.nsf/eng/sf08942.html SureCall, Inc | 1-888-365-6283 | support@surecall.com | www.surecall.com... -
Page 15: Warranty
Buyers may obtain an RMA number for warranty returns by calling the SureCall Return Department toll-free at 1-888-365-6283. Any returns received by SureCall without an RMA number clearly printed on the outside of the shipping container will be returned to sender. In order to receive full credit for signal boosters, all accessories originally included in the signal booster box must be returned with the signal booster. - Page 16 SureCall, Inc 48346 Milmont Drive Fremont, California 94538, USA 888.365.6283 | www.surecall.com...
