multicomp pro MP700506 User Manual page 80

Absolute Amplitude
Accuracy
Uncertainty
VSWR
Distortion and spurious response
Second harmonic
distortion
Third-order
intermodulation
1 dB Gain
Compression
Residual response
MP700507
20℃ to 30℃, fc=50 MHz, Span=200 kHz ,
RBW=10 kHz, VBW=10 kHz, peak
detector, 10 dB RF attenuation,95%
confidence level
Preamp Off ±0.4 dB, input signal level
-20 dBm
Preamp On ±0.5 dB, input signal level
-40 dBm
Input signal range 0 dBm to -50 dBm
±1.5 dB
Input 10 dB RF attenuation, 1MHz to 3.6
GHz
<1.5, Nominal
fc ≥ 50 MHz, Preamp off, signal input -10
dBm, 0 dB RF attenuation, 20℃ to 30℃
-65 dBc
fc ≥ 50 MHz, Input double tone level -20
dBm, frequency interval 100 kHz, input
attenuation 0 dB, preamplifier off, 20℃ to
30℃
+10 dBm
fc ≥ 50 MHz, 0 dB RF attenuation,
Preamp off , 20℃ to 30℃
>+2 dBm, nominal
connect 50 Ω load at input port, 0 dB
input attenuation, 20℃ to 30℃
<-85 dBm, typical
76
20℃ ~ 30℃, fc=50
MHz, Preamplifier Off,
20 dB RF attenuation,
input signal 1~50dB
±0.5 dB
