Source】 Hardkey - multicomp pro MP700506 User Manual

detects a video signal in which the voltage exceeds the specified
video trigger level.
Use the numeric keys, control or direction keys to set the trigger
level in Video mode. The screen will display corresponding line
Triger Level and the value.
5.11.3 [External ►]
In this mode, an external signal (TTL signal) is input from the [Trig
In] connector at the top panel, of which the edge conditions should
meet with the user settings to generate trigger signals.
Press [External ►] to access the submenu, select [Positive Edge]
or [Negative Edge] as the trigger condition.
5.12 【Source】 hardkey
Key access:
Press Shift key, then Source hardkey (6 in numeric keypad).
When the Source is turned on, an independent signal or a signal
with the same frequency of the current sweep signal will be output
from the GEN Output 50Ω terminal on the top panel. Press the key
to access the submenu includes [Output On Off], [Source GEN CW
TG], [Output Level], [Output FREQ], [OF Step], [Network Meas ►].
The source is turned off in the power-on and reset states.
5.12.1 [Output On Off]
Turn on/off the output of the GEN Output 50Ω terminal on the top
panel.
5.12.2 [Source Gen CW TG]
Select source as CW (Continuous Wave) or TG (Tracking
Generator).
CW: Output independent continuous wave signal. (CW output
function is only for specific models.)
TG: RF output and spectrum reception are fully synchronized on
the frequency sweep, and the tracking source frequency can not
be set individually.
55
