The menu for system parameter settings includes [System ►],
[Setting ►], [PowerOn/Preset ►], [Calibration ►], [Printer ►],
[Save/Recall ►]. For first time you use the spectrum analyzer, set
the system settings, the system will store the settings, restart the
machine after power off won't change the settings.
5.14.1 [System ►]
Access system information, firmware update, and option submenu.
5.14.1.1 [System Info]
Display the current system information, such as serial number,
firmware version, temperature, MAC address, etc.
5.14.1.2 [Firmware Update]
To update your instrument firmware, do the following:
1. Create a folder named "spectrum" (lowercase) on the root
directory of the USB memory device, and copy the firmware file
onto this folder.
2. Insert the USB memory device into the top panel USB connector
on your instrument. Press
Press [System ►], and press [Firmware Update] to execute
firmware update.
3. The analyzer will perform the update process. The upgrade
procedure will take approximately 30 seconds. During the
update process, do not remove the USB memory device, do not
power off the instrument or press any key. If the update process
fails, please report the problem to your distributor or our
technical support.
4.Once the upgrade is completed, the instrument will automatically
restart.
5.14.1.3 [Option]
Access the option submenu. TG, EMI, CW can be selected as
option.
5.14.2 [Setting ►]
Access the submenu for setting the analyzer, including [LAN ►],
Shift key, then System hardkey.
