RF Input
④
connector
(50 Ω)
External power
⑤
connector
LED indicator
⑥
GPS/BDS
⑦
antenna
connector
USB Device
⑧
interface
LAN interface
⑨
USB Host
⑩
interface
Headphone
⑪
jack
N type female connector. Connector for RF
input.
CAUTION
!
Input voltage at RF input port must not be higher
than 50 V DC to avoid damage to the attenuator
and input mixer tracking generator.
When input attenuator is higher than 10 dB, the
RF port input signal must be less than +30 dBm.
Provides input for the DC power source via
an AC-DC adapter.
Green light when external DC power is
connected. Red light when the battery is
charging. Blinking light when charge
suspend or battery absent.
SMA-female type. Connects an GPS/BDS
Antenna to offer the GPS location for the
field testing. Active antenna supported.
MICRO-USB type. Connects to a PC. This
USB interface supports PictBridge printer
and remote-control connection.
Through this interface, the analyzer can be
connected to your local network for remote
control.
Type A. Connects to a USB memory stick.
Connects to a headphone.
