Date/time
⑥
Battery
⑦
charge
indicator
Menu title
⑧
Marker
⑨
information
GPS/BDS
⑩
location
Trace
⑪
average
number
Submenu
⑫
softkeys
LAN access
⑬
sign
USB storage
⑭
device status
Temperature
⑮
or ANT
Sweep Time
⑯
Frequency
⑰
span or stop
frequency
Video
⑱
bandwidth
Display system date and
time
Show the battery level
Function of current menu
belongs to
Display frequency and
amplitude of current marker
Shows the GPS/BDS
location (Latitude,
Longitude) when the
GPS/BDS antenna is
inserted and is tracking
satellites.
Continuously get average of
the trace to smooth it.
Menu items of current
function, can be hidden
LAN access sign
The USB icon changes to
green when USB storage
device is inserted.
Display device internal
temperature.
If overcurrent occurs to the
GPS/BDS antenna, red
ANT will be shown.
System sweep time
Display span width or stop
frequency
Display video bandwidth
14
【System】→
[Setting] →
[Date/Time]
Marker
BW→ [Average]
【Display】 → [UI
Setting ] →[Menu
►
Hiding]
【Sweep】→
[Sweep Time]
Span→[Span] or
FREQ→[Stop
Freq]
BW→ [VBW]
