DSQD Manual

Supplied Hardware

DCR15/4AU
DC power supply
35800 Hex L
key wrench
25990 Bracket
rear tie
(4) 28885 SCR10
cap screw
(4) 35664 Rubber
foot large

Unpacking the Unit

Compare the packing list enclosed with the DSQD with
the original order. Inspect all items for damage. Im-
mediately call 1-800-821-1121 to report any items that
are missing or damaged. The sooner we get notified,
the sooner we can get any needed replacement items
shipped to your location.
NOTE: Each DSQD includes hardware to mount
two (2) DSQD receivers in a rack.
16
25991 Bracket
front tie
28950 Long Cap
35959 Hole Plug
(2) A500RA22
Antenna
Screws
27076 Rack
flange bracket
27082 Rack handle
28951 Short
spacer tubes

Items Included in the Box:

• Instruction manual
• (DCR15/4AU) Power supply cable
• (21926) USB cable
• (35800) Hex L key wrench
• (25990) Bracket rear tie
• (25991) Bracket front tie
• (27076) Rack flange bracket
• (27082) Rack handle
• (28885) (4) SCR10 cap screw
• (28951) (2) Short spacer tubes
• (28950) (2) Long cap screw
• (35664) (4) Rubber foot large
• (35959) Hole plug
• (A500RA20) (2) Antenna
• (A500RA22) (2) Antenna
21926
Cable USB
(2) A500RA20
Antenna
LECTROSONICS, INC.
