Specifications
Environmental Characteristics
Operating temp. range
Operating humidity
Outdoor usage
Mechanical
Size
(Height x Width x Depth)
Weight
*Measured using Rosslare proximity card (AT-14) or equivalent.
Range also depends on electrical environment and proximity to
metal.
2.1

Key Features

The key features for the AYC- F/G/M60 series are:
• Built-In Proximity Card Reader (125 KHz ASK/FSK
Modulation) (for 60 series only)
• Patented, programmable Blue backlit keypad
• Optical back tamper sensor and open controller tamper
output.
• Lockout feature on wrong entry (Keypad / Card Tamper)
• Internal buzzer provides audible interface feedback
• Two status / programming Interface LEDs (tri-colored)
• Fully potted construction for outdoor use
• Comes with mounting template for easier installation
• Comes with an installation kit that includes a security
screw and a security screw tool
AYC-Qx4
family
manual
AYC- F/G/M60
-22 to 150° F (-30 to 65° C)
0 – 95% (non-condensing)
Weather-resistant, meets IP-65, epoxy
potted, suitable for outdoor use
F: 4.72 x 3 x 0.827 inches
G: 5.39 x 1.73 x 0.83 inches (137 x 44 x21 mm)
M: XXXXXXXXX
F: 1.05 lb (480g)
M: XXXXXX
(120 x 76 x 21 mm)
(XXXXXX)
G: 0.35 lb (160g)
