Rosslare AC-015 Manual

Single door access control programmer
Hide thumbs Also See for AC-015:
Table of Contents

Advertisement

Quick Links

Single Door Access
Control Programmer
AC-015
MODE
1
4
7
March 2008
DOOR
2
3
5
6
8
9
0
#

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC-015 and is the answer not in the manual?

Questions and answers

Related Manuals for Rosslare AC-015

Summary of Contents for Rosslare AC-015

  • Page 1 Single Door Access Control Programmer MODE DOOR AC-015 March 2008...
  • Page 3 © Copyright 2000 Rosslare. All rights reserved. Rosslare, the Rosslare logo, and the Rosslare products referred to herein are either the trademarks or registered to the trademarks of Rosslare, All other trademarks are the property of their respective owners. Software License Agreement.
  • Page 4 Rosslare or all copies of the Software destroyed. Limited Product Warranty. Rosslare warrants that any hardware products accompanying this documentation shall be free from significant defects in material and workmanship for a period of one year from the date of purchase.
  • Page 5 Consistent with 48. C.F.R. 12.212 and 48 C.F.R. 227.7202-1 through 227.7204-1 (June 1995), or any successor regulations, this software is provided to the terms and conditions herein. Contractor/ Manufacturer Rosslare Enterprises Ltd. 12 Wang Tai Road, Hong Kong. AC-015...

  • Page 7: Table Of Contents

    Events and Event Actions ......21 Programming Instructions......23 Programming Menu Quick Reference Guide ............. 24 Programming the AC-015 ......25 Replacing a Lost Programming Code ... 45 Replacing a Lost Normal / Secure Code ..46 Accessories............47 TECHNICAL SUPPORT........50...

  • Page 8: Introduction

    The AC-015 provides a higher level of security as the programmer is normally placed in a secure location while the reader sensor is remotely located outside the premises to be controlled.
  • Page 9 A record form is enclosed for your reference to assist you with your record keeping. The AC-015 is capable of learning both PIN codes (keyboard based codes - 4 digit codes) and Proximity codes (received from proximity card reader). The system can be connected to up to two reader sensors.

  • Page 10: Key Features

    Key Features AC-015 system key features: • RS-232 PC Interface • Multi-language PC software • Supports up to 500 employees • Realtime System Monitoring • Supports 26-Bit Wiegand compatible Readers • Three Modes of Operation Normal Mode Bypass Mode Secure Mode •...

  • Page 11: Technical Specifications

    N.O. or N.C. option Tamper Relay 1A Relay N.C. Dry Contact Output Reader Power Voltage: 12V DC Supply: Max Current: 300mA Inputs Release to Exit N.O. Dry Contact (REX): Two Reader Inputs: 26-Bit Wiegand Compatible AC-015 Page 9 March 2008...
  • Page 12 Operating -25°F to 145°F Temperature: -31°C to 63°C Operating Humidity: 0 to 95% (Non-Condensing) Mechanical Characteristics Dimensions: 5.3 x 3.4 x 1.2 inch LxWxD 134x 85 x30mm (Fits US Gang Box) Weight: 0.5 lbs (220g) AC-015 Page 10 March 2008...

  • Page 13: Installation

    Wiring diagrams are also provided for attaching the controller to the REX button, and External 26-Bit Wiegand Compatible readers. Also covered in this section is how to wire the AC-015 to a PC. Topics in this section: • Mounting the Controller •...

  • Page 14: Mounting The Controller

    3) (Skip this step when attaching the AC-015 to a US Gang Box) Drill a hole for cables as indicated on the wiring template.
  • Page 15 7) Return and secure the front case using the security screw and security tool provided in the Installation Kit. Door LED Mode LED MODE DOOR 3 x 4 Matrix Keypad Bell Button Case Screw You now have mechanically installed the controller. AC-015 Page 13 March 2008...

  • Page 16: Power Wiring

    Wiring Power wiring POWER SUPPLY FROM TRANSFORMER 16V AC (1.5A, 25VA) MODE DOOR 12V DC LEAD ACID BATTERY UP TO 7 AH RECOMMENDED Typical Lock and Option Wiring MODE DOOR N.C. N.O. Common N.C. AC-015 Page 14 March 2008...

  • Page 17: Reader Wiring

    Reader Wiring MODE DOOR +12V +12V READER 12V DC, Max. 300mA READER 12V DC, Max. 300mA Connecting a Controller to a PC DOOR MODE To PC Serial Port (COM Port) AC-015 Page 15 March 2008...

  • Page 18: Features And Concepts

    Features and Concepts Now that you have installed your AC-015 controller, it is time to become familiar with its features and concepts. In this section you will learn about all the features that are programmable. They are the basic features of the AC-015 and can be programmed directly from the controller’s programming keypad.

  • Page 19: Modes Of Operation

    Modes of Operation The AC-015 has three modes of operation Normal, Bypass, and Secure Mode. The three modes provide different levels of security. Normal Mode • The MODE LED is green Mode Door GREEN • In this mode the Controller is in the normal level of security.
  • Page 20 Release Time. • In addition, it is possible to activate the Lock Strike in the following ways: a. Pressing the REX button b. Master Codes (from an outside reader only using Prox. Code or Pin. Code) AC-015 Page 18 March 2008...

  • Page 21: Changing The Modes Of Operation

    Normal/Secure Code). • The MODE LED will Mode Door flash green GREEN Press the “#” key • The MODE LED will Mode Door turn green GREEN • You are now in Normal Mode AC-015 Page 19 March 2008...
  • Page 22 Enter your 4-digit Normal/ Bypass Code • The MODE LED will Mode Door flash green GREEN Press the “#” key • The MODE LED will Mode Door turn green GREEN • You are now in Normal Mode AC-015 Page 20 March 2008...

  • Page 23: Events And Event Actions

    Events and Event Actions Tamper Event A tamper event will cause AC-015 tamper output to open and alarm sound generated if enabled. A tamper event may occur due to several reasons: • AC-015 cover is removed or broken. • A reader sensor wire is being disconnected from the AC-015 reader input terminal.
  • Page 24 REX button is released, plus the "Lock Strike Release Time". In this case the "Lock Strike Relay" only begins its count down once the REX button has been released. Door opening due to REX button will never generate chime sound. AC-015 Page 22 March 2008...

  • Page 25: Programming Instructions

    AC- 015’s features. Most of these features can be programmed via the AC-015’s programming keypad. The following pages describe how to program the AC-015 using the programming keypad. Topics in this section: •...

  • Page 26: Programming Menu Quick Reference Guide

    Changing Program Code Changing Normal/Secure Code Changing Normal/Bypass Code Changing Door Release Time Choosing Fail Secure/Fail Safe Operation Enrolling Proximity Cards or Keyboard Codes Deleting Proximity Cards or Keyboard Codes Returning to Default Factory Setting AC-015 Page 24 March 2008...
  • Page 27 Setting and Program Facility Code *0000 deletes a function NOTE: You must be in NORMAL mode to program the AC-015. The Mode LED will be green. Wrong or timed out entries will reset the controller to the NORMAL mode condition. AC-015...
  • Page 28 Wrong entries during programming may also abort programming, along with long beep generation. All programming operations are done either from the on-board keyboard or from the external reader. Programming PROX. employee codes requires using proximity reader and proximity cards. AC-015 Page 26 March 2008...
  • Page 29 Entering Programming Mode To begin programming the controller’s settings, the AC-015 must first place into Programming Mode. You may only enter Programming mode from Normal mode, the controller does not permit entry to Programming Mode if the controller is in Bypass and Secure Mode.
  • Page 30 Wrong entries may reset the controller back to Normal Operating Mode. While in Programming Mode if no key is pressed for 30 seconds the AC-015 will emit a long beep and return to Normal Operating Mode. A short press on the “#” key may also return the...
  • Page 31 ? ? ? ? code you wish to set as Lock Strike Code 1. • You will hear 3 beeps • The system will return to NORMAL mode • The default Lock Strike Code 1 is 2580 AC-015 Page 29 March 2008...
  • Page 32 Lock Strike Code 2. • You will hear 3 beeps • The system will return to Normal mode NOTE: There is no default code for Lock Strike Code 2. AC-015 Page 30 March 2008...
  • Page 33 Programming Code • You will hear 3 beeps • The system will return to Normal mode NOTE: Programming Code cannot be erased. Programming code 0000 is not valid and will not erase the programming code. AC-015 Page 31 March 2008...
  • Page 34 ? ? ? ? code you wish to set as the new Normal/Secure change code. • You will hear 3 beeps • The system will return to Normal mode • The default Secure Code is 3838 AC-015 Page 32 March 2008...
  • Page 35 • The MODE LED will flash orange NOTE: The Normal / Bypass Code also controls the Chime function for the AC-015. You may set the code to 4 available options. Option 1: Disable Bypass Mode - Disable Chime • Enter 0000. The Bypass Mode and the Chime function are disabled.
  • Page 36 0. The Bypass mode and the Chime function are enabled for both Normal mode and Bypass mode. • You will hear 3 beeps • The system will return to Normal mode NOTE: No default Bypass code exists. AC-015 Page 34 March 2008...
  • Page 37 (from 01 to 99 seconds). For Fail Secure Operation: • Enter 0 for the first digit For Fail Safe Operation: • Enter 1 for the first digit AC-015 Page 35 March 2008...
  • Page 38 5-minute tamper alarm sound time and a 12 second door release.) • You will hear 3 beeps. • The system will return to Normal mode. • Default door open time is 4 seconds. AC-015 Page 36 March 2008...
  • Page 39 If an unassigned proximity card is enrolled at an occupied slot, the AC-015 will generate a long beep and wait for another slot number to be entered. The card at the current slot location must be erased first, before a new code is programmed on that slot number.
  • Page 40 NOTE: The AC-015 programmer will not accept employee codes that are already allocated to a slot. The AC-015 will signal this with a long beep and the MODE LED will continue to flash green. AC-015...
  • Page 41 • You will hear a long beep • The AC-015 will return to Normal mode NOTE: If the programming period times out before you press the “#” key, the controller will emit a long beep and return to Normal mode.
  • Page 42 • The MODE LED will Mode Door flash red ORANGE Enter 4-digit ? ? ? ? Programming Code (this last step confirms that you intentionally want to delete employee from the system). AC-015 Page 40 March 2008...
  • Page 43 Then, if you wish to delete a lost or stolen employee code from the system, you can identify the card number from your record. AC-015 Page 41 March 2008...
  • Page 44 Press 0 again • The DOOR LED will Mode Door continue flashing red • The MODE LED will flash red Enter 4-digit ? ? ? ? Programming Code. (This last step confirms that you intentionally want to AC-015 Page 42 March 2008...
  • Page 45 Code (must be between 0-255). • The MODE LED will Mode Door turn green GREEN • The DOOR LED will continue flashing red • If the wrong code is entered the system will exit programming. AC-015 Page 43 March 2008...
  • Page 46 Facility Code to disappear while still occupying the code slot number. • If Facility Code is not 000, programming any Proximity Card with another Facility Code is prohibited, however, PIN codes are not affected. AC-015 Page 44 March 2008...

  • Page 47: Replacing A Lost Programming Code

    Programming Mode so that you may create a new Programming Code. The AC-015 must be in Normal Mode otherwise this will not work. Make sure that the MODE LED is green before proceeding. Disconnect power from the AC-015...

  • Page 48: Replacing A Lost Normal / Secure Code

    Secure Mode, complete the following procedure to re-enter Normal Mode so that you may program a new Normal / Secure Code. The AC-015 must be in Secure Mode otherwise this will not work. Make sure that the MODE LED is red before proceeding.

  • Page 49: Accessories

    • Slim Stylish Design (Mullion) • Includes LED Indicator • Audible Buzzer Indicator • Built in Tamper (w/ Rosslare Controllers) • Includes Bell Button (w/ Rosslare Controllers) AY-X11 Series Prox Readers w/ Bell AY-C11 / AY-D11 • Reading Distance: 8 to 10cm •...
  • Page 50 For indoor use • Slim Stylish Design (USA Gang Box) • Bi-Color Light Indicator • Audible Buzzer Indicator (w/ Rosslare Controllers) • Built in Tamper (w/ Rosslare Controllers) AY-X12 Series Prox Readers AY-H12 / AY-J12 / AY-K12 / AY-L12 / AY-M12 •...
  • Page 51 • Slim Stylish Design (USA Gang Box) • Bi-Color Light Indicator • Audible Buzzer Indicator • Built in Tamper (w/ Rosslare Controllers) • Includes Bell Button (w/ Rossalare Controllers) AY-L23 RF Reader AY-L23 • Read Range: 70 meters (200 feet) •...

  • Page 52: Technical Support

    Technical Support Asia Pacific, Middle East, Africa Rosslare Security Products Headquarters 905-912 Wing Fat Industrial Bldg, 12 Wang Tai Road, Kowloon Bay Hong Kong Tel: +852 2795-5630 Fax: +852 2795-1508 E-mail: support.apac@rosslaresecurity.com United States and Canada 1600 Hart Court, Suite 103...
  • Page 54 www.rosslaresecurity.com...
