1. General Information

1.1

Introduction

The AYC-F/G/M60 series is a vandal-resistant, waterproof,
standalone, convertible integrated reader and controller. The
AYC-F/G/M60 series automatically determines whether to function
as a reader or as a controller. If the unit is connected to a
standard access control unit, then it functions as a reader. If the
unit is connected to Rosslare's secure application appurtenances
such as the PS-A25T, PS-C25T or PS-C25TU, it functions as a secured
controller.
For information on how the unit functions as a reader, see Reader
Functionality on page 14. For information on how the unit
functions as a controller, see Controller Functionality on page 28.
All of the units are water resistant and suitable for indoor or
outdoor mounting. As a controller, the units accept up to 500
users, and allow entry via a personal identification number (PIN)
and/or by presenting a proximity card. The pin code length for the
controller has several options. The pin code length can be a set
number of 4, 5 or 6 digits or it can be a 4-8 digits option.
This manual contains the following information: Installation, Wiring
instructions, and Operation Instructions.
1.2

Reader/Controller Types

The different types of units of this series are:
• Type 54 has PIN only
• Type 60 has PIN and Proximity card
AYC-F/G/M54
AYC-F/G/M60
AYC-Qx4
family
Backlight
manual
Keypad Type
Standard
Standard
Proximity
